第3页_现代Hyundai_Part Number_广州千韧科技有限公司

2025/01/21

现代零件查询HBF15/18T-5 3-SPOOL CONTROL VALVE(OPTION,NEW)EPC Hyundai

Pos.Part NoQtyParts nameComments*.32FP-02000[1] MAIN CONTROL VALVE HBF15T-5 *.32FP-02000[1] MAIN CONTROL VALVE HBF18T-5 1.XKBF-00443[1] SECTION-INLET 2.XKBF-00444[1] SECTION-LIFT 3.XKBF-00445[1] SECTION-TILT 4.XKBF-00446[1] SECTION-AUX1 5.XKBF-00447[1] SECTION-OUTLET 6.XKBF-00302[1] RELIEF VALVE ASSY AUX,HBF15T-5 6.XKBF-00867[1] RELIEF VALVE ASSY AUX,HBF15T-5 6.XKBF-00302[1] RELIEF VALVE ASSY AUX,HBF18T-5 6.XKBF-00867[1] RELIEF VALVE ASSY AUX,HBF1

2025/01/21

现代零件查询HBF15/18T-5 3-SPOOL CONTROL VALVE(OPTION,OLD)EPC Hyundai

Pos.Part NoQtyParts nameCommentsN*.B51600010[1] CONTROL VALVE-3SPOOL 1.XKBF-00277[6] O-RING 2.XKBF-00337[6] DUST SEAL 3.XKBF-00276[3] SEAL PLATE 4.XKBF-00279[6] SPRING SEAT 5.XKBF-00280[3] RETURN SPRING 6.XKBF-00283[3] SPACER BOLT 7.XKBF-00282[3] RETURN CAP 8.XKBF-00338[6] SOCKET HEAD BOLT 9.XKBF-00294[1] TILT LOCK PLUNGER 10.XKBF-00339[1] TILT LOCK SPRING 11.XKBF-00293[1] O-RING 12.XKBF-00292[1] TILT LOCK PLUG 13.XKBF-00340[2] NUT 14.XKBF-00341[4] NUT

2025/01/21

现代零件查询HBF15/18T-5 2-SPOOL CONTROL VALVE(STD)EPC Hyundai

Pos.Part NoQtyParts nameComments*.32FP-02000[1] MAIN CONTROL VALVE HBF15T-5 *.31FP-02000[1] MAIN CONTROL VALVE HBF18T-5 *.31FP-02000[1] MAIN CONTROL VALVE 1.XKBF-00443[1] SECTION-INLET 2.XKBF-00444[1] SECTION-LIFT 3.XKBF-00445[1] SECTION-TILT 5.XKBF-00447[1] SECTION-OUTLET 6.XKBF-00302[1] RELIEF VALVE ASSY AUX,HBF15T-5 6.XKBF-00867[1] RELIEF VALVE ASSY AUX,HBF15T-5 6.XKBF-00302[1] RELIEF VALVE ASSY AUX,HBF18T-5 6.XKBF-00867[1] RELIEF VALVE ASSY AU

2025/01/21

现代零件查询HBF15/18T-5 TILT HYDRAULIC PIPINGEPC Hyundai

Pos.Part NoQtyParts nameComments1.P010-110004[1] CONNECTOR 2.P623-085015[1] HOSE ASSY-THD 0X90 3.X500-110013[2] CONNECTOR-ORFS 4.P930-043008[2] HOSE ASSY-ORFS 0X90 5.31FY-70010[1] TEE BLOCK ASSY 6.S035-083526[1] BOLT-W/WASHER 7.X520-110012[4] ELBOW-90,ORFS 8.P930-043011[2] HOSE ASSY-ORFS 0X90 9.P910-043016[1] HOSE ASSY-ORFS 0X0 10.P910-043018[1] HOSE ASSY-ORFS 0X0 12.31FE-70080[2] SPACER-TILT CYLINDER 13.31FE-70220[AR] SHIM 14.1223003100-06[4] PIN-TILT CYL

2025/01/21

现代零件查询HBF15/18T-5 STEERING HYDRAULIC PIPINGEPC Hyundai

Pos.Part NoQtyParts nameComments4.31FG-10010[3] ELBOW-90 5.F53610090[1] ELBOW-90 6.X500-310001[1] CONNECTOR-ORFS 7.P920-063041[1] HOSE ASSY-ORFS 0X45 8.P920-063053[2] HOSE ASSY-ORFS 0X45 9.P930-043034[1] HOSE ASSY-ORFS 0X90 HBF15T-5 9.P930-043032[1] HOSE ASSY-ORFS 0X90 HBF15T-5 9.P930-043034[1] HOSE ASSY-ORFS 0X90 HBF18T-5 9.P930-043032[1] HOSE ASSY-ORFS 0X90 HBF18T-5 10.P760-013205[1] HOSE-RUBBER LOW 11.X515-109524[1] CONNECTOR-LONG,ORFS 12.31FG-1002

2025/01/21

现代零件查询HBF15/18T-5 4-SPOOL CONTROL VALVE LEVER(OPTION)EPC Hyundai

Pos.Part NoQtyParts nameComments2.B51600033[1] BRACKET-MCV HBF15T-5 2.B51600034[1] BRACKET-CONTROL VALVE HBF15T-5 2.B51600033[1] BRACKET-MCV HBF18T-5 2.B51600034[1] BRACKET-CONTROL VALVE HBF18T-5 3.S035-083526[1] BOLT-W/WASHER HBF15T-5 3.S035-083522[1] BOLT-W/WASHER HBF15T-5 3.S035-083526[1] BOLT-W/WASHER HBF18T-5 3.S035-083522[1] BOLT-W/WASHER HBF18T-5 4.S015-080206[2] BOLT-HEX HBF15T-5 4.S015-080202[2] BOLT-HEX HBF15T-5 4.S015-080206[

2025/01/21

现代零件查询HBF15/18T-5 3-SPOOL CONTROL VALVE LEVER(OPTION)EPC Hyundai

Pos.Part NoQtyParts nameComments2.B51600033[1] BRACKET-MCV HBF15T-5 2.B51600034[1] BRACKET-CONTROL VALVE HBF15T-5 2.B51600033[1] BRACKET-MCV HBF18T-5 2.B51600034[1] BRACKET-CONTROL VALVE HBF18T-5 3.S035-083526[1] BOLT-W/WASHER HBF15T-5 3.S035-083522[1] BOLT-W/WASHER HBF15T-5 3.S035-083526[1] BOLT-W/WASHER HBF18T-5 3.S035-083522[1] BOLT-W/WASHER HBF18T-5 4.S015-080206[2] BOLT-HEX HBF15T-5 4.S015-080202[2] BOLT-HEX HBF15T-5 4.S015-080206[

2025/01/21

现代零件查询HBF15/18T-5 2-SPOOL CONTROL VALVE LEVEREPC Hyundai

Pos.Part NoQtyParts nameComments*.@[1] 2-SPOOL MCV LEVER HBF15T-5 *.@[1] 2-SPOOL MCV LEVER HBF18T-5 2.B51600034[1] BRACKET-CONTROL VALVE 3.S035-083522[1] BOLT-W/WASHER 4.S015-080202[2] BOLT-HEX 5.S205-081002[1] NUT-HEX 6.S411-080002[2] WASHER-SPRING 7.B51600040[1] ROD 8.B51600050[2] ROD 9.31FY-40010[1] LEVER-LIFT 10.31FY-40020[1] LEVER-TILT 11.31FG-40500[1] KNOB-LIFT 12.31FG-40510[1] KNOB-TILT 13.B51330030[1] SHAFT 14.B51600110[2] SPACER 15.S035

2025/01/25

现代零件查询R25Z-9AK NH MAIN BEARING CASEEPC Hyundai

Pos.Part NoQtyParts nameComments*.14MK-00011[1] ENGINE ASSY 010.XJBR-02373[1] BEARING CASE ASSY 020.XJBR-02374[2] BOLT-BEARING CASE 025.XJBR-02375[1] METAL-CRANKSHAFT STD SET 025.XJBR-02376[1] METAL-CRANKSHAFT -0.20MM SET 025.XJBR-02377[1] METAL-CRANKSHAFT -0.40MM SET 030.XJBR-02378[1] GASKET-BEARING CASE 040.XJBR-02379[1] COVER-BEARING CASE 050.XJBR-02380[1] SEAL-OIL 060.XJBR-02381[1] GASKET 070.XJBR-02382[8] BOLT 080.XJBR-02383[9] BOLT 090.XJBR-0238

2025/01/25

现代零件查询R25Z-9AK NH CAMSHAFT AND IDLE GEAR SHAFTEPC Hyundai

Pos.Part NoQtyParts nameComments*.14MK-00011[1] ENGINE ASSY 010.XJBR-02390[6] TAPPET 020.XJBR-02391[6] PUSH ROD 030.XJBR-02392[1] CAMSHAFT ASSY 040.XJBR-00668[1] BALL 050.XJBR-02393[1] GEAR-CAM 060.XJBT-00854[1] KEY-FEATHER 070.XJBR-02394[1] STOPPER-CAMSHAFT 080.XJBR-00612[2] BOLT-SEMS 090.XJBR-02395[1] IDLE GEAR ASSY 100.XJBR-02396[1] BUSH-IDLE GEAR 110.XJBR-02397[1] COLLAR-IDLE GEAR 120.XJBR-02398[1] COLLAR-IDLE GEAR 130.XJBR-02399[1] CIRCLIP-IDLE GEAR

2025/01/25

现代零件查询R25Z-9AK NH PISTON AND CRANKSHAFTEPC Hyundai

Pos.Part NoQtyParts nameComments*.14MK-00011[1] ENGINE ASSY 180.XJBR-02428[3] PISTON KIT STD 180.XJBR-02429[3] PISTON KIT +0.50MM 010.XJBR-02401[3] PISTON STD 010.XJBR-02402[3] PISTON RING ASSY +0.50MM 020.XJBR-02625[3] PISTON STD 020.XJBR-02404[3] PISTON RING ASSY +0.50MM 030.XJBR-02405[3] PISTON PIN 040.XJBR-02406[6] CIRCLIP-PISTON PIN 060.XJBR-02408[1] BUSH-PISTON PIN 050.XJBR-02407[3] CONNECTING ROD ASSY 060.XJBR-02408[1] BUSH-PISTON PIN

2025/01/25

现代零件查询R25Z-9AK NH FLYWHEELEPC Hyundai

Pos.Part NoQtyParts nameComments*.14MK-00011[1] ENGINE ASSY 010.XJBR-02433[1] FLYWHEEL ASSY 020.XJBR-02434[1] GEAR-RING 030.XJBR-02435[6] BOLT-FLYWHEEL 040.XJBR-02436[1] HOUSING-FLYWHEEL 050.XJBR-02437[8] BOLT 060.XJBT-00155[1] COVER 070.XKDL-00221[1] BOLT-WASHER 080.XKDL-00272[1] WASHER

2025/01/23

现代零件查询R290LC-7 DOUBLE ACTING HYD PIPING KIT 1EPC Hyundai

Pos.Part NoQtyParts nameComments*.@[1] D/ACT HYD PIPING KIT W/O ACCUM N*.31N8-91710[1] D/ACT HYD KIT N*.31N8-94710[1] D/ACT HYD KIT N*.31N8-94711[1] D/ACT HYD KIT *-1.31N8-92010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-92011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-91410[1] D/ACT MAIN PIPING KIT *-11.31N8-91411[1] D/ACT MAIN PIPING KIT *-11.31N8-9141

2025/01/23

现代零件查询R290LC-7 DOUBLE ACTING HYD PIPING KIT 2EPC Hyundai

Pos.Part NoQtyParts nameComments*.@[1] D/ACT HYD PIPING KIT WITH ACCUM *.31N8-91810[1] D/ACT HYD KIT N*.31N8-94810[1] D/ACT HYD KIT N*.31N8-94811[1] D/ACT HYD KIT *-1.31N8-92010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-92011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-91410[1] D/ACT MAIN PIPING KIT *-11.31N8-91411[1] D/ACT MAIN PIPING KIT *-11.31N8-9141

2025/01/23

现代零件查询R290LC-7 SINGLE ACTING HYD PIPING KIT 1EPC Hyundai

Pos.Part NoQtyParts nameComments*.@ S/ACT HYD PIPING KIT W/O ACCUM N*.31N8-91110[1] S/ACT HYD KIT N*.31N8-94110[1] S/ACT HYD KIT N*.31N8-94111[1] S/ACT HYD KIT *-1.31N8-91010[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-91011[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-94010[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-94011[1] S/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-91210[1] S/ACT MAIN PIPING KIT SEE 3720 *-11.31N8-91211[1] S/ACT MAIN PIPING KIT SEE

2025/01/23

现代零件查询R290LC-7 SINGLE ACTING HYD PIPING KIT 2EPC Hyundai

Pos.Part NoQtyParts nameComments*.@ S/ACT HYD PIPING KIT WITH ACCUM *.31N8-91610[1] S/ACT HYD KIT N*.31N8-94610[1] S/ACT HYD KIT N*.31N8-94611[1] S/ACT HYD KIT *-1.31N8-91010[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-91011[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-94010[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-94011[1] S/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-91210[1] S/ACT MAIN PIPING KIT SEE 3720 *-11.31N8-91211[1] S/ACT MAIN PIPING KIT SEE

2025/01/23

现代零件查询R290LC-7 LOWER ENGINE GASKET SET(-#0111)EPC Hyundai

Pos.Part NoQtyParts nameComments*.3800558[1] LOWER ENG GASKET SET 3800558 .3353977[1] SEAL SERVICE KIT-FR .3901798[1] WASHER-SEALING .3902089[1] SEAL/O-RING .3902425[1] WASHER-SEALING .3905928[6] NOZZLE-PISTON COOL .3912473[1] SEAL-RECT RING .3913994[1] O-RING .3914095[1] SEAL-RECT RING .3914301[1] GASKET-REAR COVER .3914302[1] GASKET .3914308[1] GASKET-LUB OIL CVR .3915772[1] SEAL-RECT RING .3916042[1] GASKET-HYD PUMP .3916284[1] SEAL-O-RING .3917

2025/01/23

现代零件查询R290LC-7A DOUBLE ACTING HYD PIPING KIT 1EPC Hyundai

Pos.Part NoQtyParts nameComments*.@[1] D/ACT HYD PIPING KIT W/O ACCUM N*.31N8-94710[1] D/ACT HYD KIT N*.31N8-94711[1] D/ACT HYD KIT *-1.31N8-95010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-94410[1] D/ACT MAIN PIPING KIT *-12.31N8-91312[1] ATTACH PIPING KIT *-12.31N8-91313[1] ATTACH PIPING KIT 45.31N8-99560[1] PORT RELIEF VALVE SEE 3620,25 46.31N8-99570[1] PORT RELIEF VALVE SEE 3620,25 47.34E7-04720[1]

2025/01/23

现代零件查询R290LC-7A DOUBLE ACTING HYD PIPING KIT 2EPC Hyundai

Pos.Part NoQtyParts nameComments*.@[1] D/ACT HYD PIPING KIT WITH ACCUM N*.31N8-94810[1] D/ACT HYD KIT N*.31N8-94811[1] D/ACT HYD KIT *-1.31N8-95010[1] D/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-95011[1] D/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-94410[1] D/ACT MAIN PIPING KIT *-12.31N8-91312[1] ATTACH PIPING KIT *-12.31N8-91313[1] ATTACH PIPING KIT 45.31N8-99560[1] PORT RELIEF VALVE SEE 3620,25 46.31N8-99570[1] PORT RELIEF VALVE SEE 3620,25 47.34E7-04720[1

2025/01/26

现代零件查询R290LC-7A SINGLE ACTING HYD PIPING KIT 1EPC Hyundai

Pos.Part NoQtyParts nameComments*.@ S/ACT HYD PIPING KIT W/O ACCUM N*.31N8-94110[1] S/ACT HYD KIT N*.31N8-94111[1] S/ACT HYD KIT *-1.31N8-94010[1] S/ACT PIPING KIT 6.25BM+3.05AM *-1.31N8-94011[1] S/ACT PIPING KIT 6.25BM+3.05AM *-11.31N8-94210[1] S/ACT MAIN PIPING KIT SEE 3720 *-12.31N8-91312[1] ATTACH PIPING KIT SEE 3635 *-12.31N8-91313[1] ATTACH PIPING KIT SEE 3635 39.21E6-30540[1] SWITCH-BREAKER SEE 3720 40.31N8-99560[1] PORT RELIEF VALVE SE
