| 1. |
549622R92
|
[1] |
JOINT
|
IH
ASSY, shielded single universal front half, tractor end, chain belt, or Superseded by part number: 542775R92
|
| 1. |
542775R92
|
[1] |
SPARE PART
|
IH
JOINT ASSY, shielded single universal front half, tractor end, Hayes Dana Superseded by part number: 1281442C91
|
| 2. |
464915R1
|
[1] |
YOKE
|
IH
W/SHAFT, used with 549622R92, chain belt or Rockwell standard Superseded by part number: 464915R2
|
| 2. |
542955R1
|
[1] |
YOKE
|
IH
W/SHAFT, used with 542775R92, Hayes Dana
|
| 3. |
487083R91
|
[1] |
YOKE
|
IH
ASSY, quick detachable Superseded by part number: 1995640C1
|
| 4. |
609144R91
|
[2] |
CROSS
|
IH
KIT, center cross, Hayes Dana, used with 542775R92 and 542776R92 Superseded by part number: 84355039
|
| 4. |
480486R91
|
[2] |
CROSS
|
IH
KIT, center cross, chain belt, used with 549622R92 and 549623R92 Superseded by part number: 84355039
|
| 5. |
606177R1
|
[8] |
SNAP RING
|
IH
RING, snap, chain belt, used with 480486R91
|
| 5. |
609154R1
|
[8] |
RING
|
IH
snap, Hayes Dana, used with 609144R91 Superseded by part number: H423392
|
| 7. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, locking pin Superseded by part number: 237924A1
|
| 9. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X-WASHER, locking pin
|
| 10. |
549623R92
|
[1] |
SEAL ASSY.
|
IH
JOINT ASSY, shielded single universal rear half, implement end, chain belt, or
|
| 10. |
542776R92
|
[1] |
SHORT SHAFT
|
IH
JOINT ASSY, shielded single universal rear half, implement end, Hayes Dana Superseded by part number: 1995642C1
|
| 11. |
464918R91
|
[1] |
TUBE
|
IH
YOKE W/TUBE, chain belt or Rockwell standard, used with 549623R92 Superseded by part number: 464918R92
|
| 11. |
542886R1
|
[1] |
SHORT SHAFT
|
IH
YOKE W/TUBE, Hayes Dana, used with 542776R92
|
| 12. |
460902R1
|
[1] |
YOKE
|
IH
rear, chain belt or Rockwell standard, used with 549623R92
|
| 12. |
609148R1
|
[1] |
YOKE
|
IH
rear, Hayes Dana, used with 542776R92 Superseded by part number: 460902R1
|
| . . |
210605C1
|
[1] |
SET SCREW
|
IH
1/2-20 x 1 hex-soc-hd set
|
| . . |
114496
|
[1] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, 1/2-NF pln jam type 5 Superseded by part number: 124934
|
| 13. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, , straight, Hayes Dana 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 13. |
80711
|
[2] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8-27 65 deg lub, chain belt
|
| 14. |
549624R2
|
[1] |
SHIELD
|
IH
W/BEARING, outer, chain belt, used with 549622R92
|
| 14. |
542885R2
|
[1] |
KIT
|
IH
SHIELD W/BEARING, outer, Hayes Dana, used with 542775R92 Superseded by part number: 1995641C1
|
| 15. |
542956R1
|
[6] |
NYLON BEARING,0.312"
|
IH
nylon, used with 542775R92 and 542776R92
|
| 15. |
549626R1
|
[4] |
BEARING
|
IH
nylon, used with 549622R92 and 549623R92 Superseded by part number: 820689C2
|
| 16. |
609151R1
|
[1] |
NYLON BEARING,2.063" ID x 0.317"
|
IH
center nylon Superseded by part number: 700708997
|
| 17. |
549625R1
|
[1] |
SHIELD
|
IH
W/BEARING, inner, chain belt
|
| 17. |
542887R1
|
[1] |
SHIELD
|
IH
W/BEARING, inner, Hayes Dana Superseded by part number: 1995643C1
|
| 18. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4-28 NF, 2 straight lub Superseded by part number: 88775
|
| 19. |
455346R21
|
[1] |
PIN
|
IH
ASSY, locking Superseded by part number: 237924A1
|
