| 1. | ZA104699 | [2] |
SUPPORT |
IH- rear box |
| 2. | ZA104966 | [1] |
SUPPORT |
IH- left |
| 3. | 96326C1 | [4] |
SLEEVE |
IH- cable |
| 4. | ZA104429 | [2] |
CABLE |
IH- shield |
| 5. | ZA103138 | [2] |
FASTENER |
IH- shield |
| 6. | ZA103937 | [4] |
WASHER |
IH- retaining Superseded by part number: 1326407C1 |
| 7. | ZA104925 | [1] |
SHIELD |
IH- pickup drive |
| 8. | ZA104935 | [1] |
BOX |
IH- twine, left |
| 9. | 180042 | [4] |
BOLT,Hex, 1/4" - 20 x 1 3/4", Gr 5 |
NHBOLT - hex, 1/4 NC x 1-3/4 inch Superseded by part number: 86628570 |
| 10. | 96314C1 | [4] |
SPRING |
IH- compression |
| 11. | ZA104611 | [6] |
PLUG |
IH- rubber |
| 12. | ZA104859 | [2] |
BRACKET |
IHTENSIONER - twine |
| 13. | 9413950 | [4] |
LOCK NUT,1/4"-20, GB |
CASNUT - lock, 1/4 inch NC Superseded by part number: 280129 |
| 14. | ZA104938 | [1] |
DOOR |
IHCOVER - twine box, left |
| 15. | ZA703189 | [1] |
HINGE |
IH- cover |
| 16. | ZA105942 | [1] |
BOX, TOOL |
CASBOX - tool |
| 17. | ZA105521 | [1] |
GUIDE |
IHBRACKET - twine guide |
| 18. | ZA762975 | [4] |
CLAMP |
IH- latch |
| 19. | 324733R1 | [2] |
CLAMP,#16, 1", Spring |
IH- hose, spring wire, no. 16 type E Superseded by part number: 274085R91 |
| 20. | ZA104633 | [2] |
GUIDE |
IH- twine |
| 21. | ZA105939 | [1] |
DOOR |
CASCOVER - tool box |
| 22. | ZA105940 | [1] |
HINGE |
CAS- tool box cover |
| 23. | 407211R1 | [1] |
CLIP |
IHPIN - hair (Package of 20) |
| 24. | ZA104965 | [1] |
SUPPORT |
IH- right |
| 25. | ZA104951 | [1] |
SHIELD |
IH- floor drive |
| 26. | ZA104602 | [1] |
SHIELD |
IH- idler |
| 27. | ZA104805 | [1] |
SHIELD |
IH- inner |
| 28. | 17351R1 | [3] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2 |
IHBOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 88682 |
| 29. | ZA104945 | [1] |
SHIELD |
IH- main drive chain |
| 30. | ZA104944 | [1] |
HINGE |
IH- shield |
| 31. | 180077 | [4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5 |
IH- hex, 5/16 NC x 3/4 inch Superseded by part number: 87872 |
| 32. | ZA104882 | [1] |
GUIDE |
IHBRACKET - twine guide |
| 33. | 106969R1 | [4] |
WASHER |
IH- flat, 11/32 x 1-1/4 x 3/64 inch (9 x 32 x 1 MM) Superseded by part number: 495-81119 |
| 34. | ZA104934 | [1] |
BOX |
IH- twine, right |
| 35. | ZA104937 | [1] |
DOOR |
IHCOVER - twine box, right |
| 37. | ZA104819 | [1] |
SHIELD |
IH- lower |
| 38. | ZA104827 | [1] |
HINGE |
IH- shield |
| 39. | 118775 | [1] |
WASHER,3/8" x 13/16" x .065" |
IH- flat, 13/32 x 13/16 x 3/64 inch (10 x 21 x 1 MM) Superseded by part number: 87613282 |
| 40. | ZA104797 | [1] |
SHIELD |
IH- upper |
| 41. | 1284374C1 | [2] |
REFLECTOR |
IH- red |
