| 1. | 488837C1 | [8] |
SPRING NUT |
IH- speed, 5/16 inch |
| 2. | ZA104585 | [1] |
FILLER |
IH- right |
| 3. | 155807C1 | [8] |
BOLT,Hex Serr, 5/16" - 18 x 1" |
IH Superseded by part number: 86512168 |
| 4. | ZA105683 | [1] |
BAND |
IH- end, right Superseded by part number: 198012A1 |
| 5. | 180137 | [16] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5 |
IH- hex, 3/8 NC x 2-3/4 inch Superseded by part number: 113-248 |
| 6. | 142619H | [36] |
WASHER |
IH- flat, 13/32 x 3/4 x 7/64 inch (10 x 19 x 3 MM) Superseded by part number: 86624144 |
| 7. | ZA103012 | [36] |
TOOTH |
IHFINGER - spring Superseded by part number: ZA106550 |
| 8. | ZA105680 | [17] |
BAND |
IH- finger |
| 9. | ZA105684 | [1] |
BAND |
IH- end, left Superseded by part number: 198013A1 |
| 10. | ZA104584 | [1] |
FILLER |
IH- left |
| 11. | 432-1628 | [2] |
COTTER PIN,1/4" x 1 3/4" |
CASPin, Split (Cotter), 1/4" x 1 3/4" Superseded by part number: 87041 |
| 12. | 22050R1 | [1] |
WASHER |
IH- flat, 1-9/32 x 1-3/4 x 3/64 inch (33 x 44 x 1 MM) Superseded by part number: 87613234 |
| 13. | 557995R11 | [2] |
COLLAR |
IH- locking Superseded by part number: 47508396 |
| 14. | 192450 | [1] |
SET SCREW,Hex Soc, 5/16"-18 x 5/16" |
IHSCREW - set, headless hex socket, 5/16 NC x 5/16 inch Superseded by part number: 115321 |
| 15. | 581469R1 | [4] |
FLANGE,Bearing |
IHHOUSING - bearing |
| 16. | 617667R92 | [2] |
BALL BEARING,31.75mm ID x 62mm OD x 18mm W |
CAS- ball Superseded by part number: 84484181 |
| 17. | ZA104210 | [1] |
SHAFT |
IH- drive, pickup, 11-5/16 inch (287 MM) |
| 18. | ZA105901 | [1] |
FRAME |
CAS- pickup Superseded by part number: ZA106618 |
| 19. | ZA105818 | [17] |
BRACKET |
CAS- frame |
| 20. | 219-8 | [2] |
LUBE NIPPLE,1/4" - 28 NPTF |
CASNIPPLE, LUBE, , straight 1/4"-28 NPT x .54" lg Superseded by part number: 87414 |
| 21. | 80722 | [4] |
LUBE NIPPLE,3/16" x .55" lg, Drive |
WINFITTING - grease, drive-type, 3/16 inch |
| 22. | 154273C1 | [8] |
BOLT,Hex Serr, 3/8" - 16 x 1", Spcl |
IHSCREW - hex flange lock, 3/8 NC x 1 inch Superseded by part number: 9706726 |
| 23. | 96338C1 | [4] |
BEARING |
IHROLLER - cam follower |
| 24. | ZA105580 | [16] |
BEARING HALF,1.62" |
IHCAP - bearing half |
| 25. | 25710R1 | [4] |
WASHER |
IH- flat, hardened Superseded by part number: 86624188 |
| 26. | 120384 | [4] |
WASHER,1/2" |
IHLOCK, 1/2" Superseded by part number: 116121 |
| 27. | 120371 | [4] |
NUT,1/2"-20, G5 |
IH Superseded by part number: 280963 |
| 28. | 180122 | [36] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5 |
IH- hex, 3/8 NC x 1 inch Superseded by part number: 113-207 |
| 29. | ZA105772 | [1] |
CAM |
IH- pickup |
| 30. | ZA105905 | [4] |
BAR |
CAS- pickup |
| 31. | 298274R1 | [1] |
BUSHING |
IHSPACER - tube |
| 32. | ZA761609 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 20 tooth (Standard) |
| 32. | ZA105596 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 15 tooth (Power reduction) |
| 33. | ZA712225 | [1] |
SLIDE |
IH- chain |
