| 1. | ZA105927 | [1] |
GUIDE |
CASFRAME ASSEMBLY - tailgate, with decals |
| 2. | REF | [1] |
INSTRUCTION |
NHDECAL - warning, keep away from rear (See Figure 62) |
| 7. | ZA104923 | [1] |
WEDGE |
IH- left |
| 8. | ZA105914 | [1] |
SPACER |
CASPIN - bale ejection |
| 9. | 180122 | [3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5 |
IH- hex, 3/8 NC x 1 inch Superseded by part number: 113-207 |
| 10. | ZA104715 | [1] |
PLATE |
IH- mounting |
| 11. | 17351R1 | [2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2 |
IHBOLT - round head square neck, 3/8 NC x 1 inch, grade 1 Superseded by part number: 88682 |
| 12. | ZA104716 | [1] |
STRAP |
IH- rubber |
| 13. | 180124 | [2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5 |
IH- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011 |
| 14. | 118775 | [2] |
WASHER,3/8" x 13/16" x .065" |
IH- flat, 13/32 x 13/16 x 3/64 inch (10 x 21 x 1 MM) Superseded by part number: 87613282 |
| 15. | ZA105977 | [1] |
GUARD |
CAS- left |
| 17. | ZA105976 | [1] |
GUARD |
CAS- right |
| 19. | ZA704673 | [2] |
SPACER |
IH- 1/2 ID x 11/32 inch (13 x 9 MM) |
| 20. | 120390 | [2] |
WASHER,1/2" |
IH- flat, 9/16 x 1-3/8 x 3/32 inch (14 x 35 x 2 MM) Superseded by part number: 106265 |
| 21. | 9413956 | [2] |
LOCK NUT,1/2"-13, GB |
IHNUT - hex, 1/2 inch NC Superseded by part number: 231-4138 |
| 22. | 180181 | [2] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5 |
IH- hex, 1/2 NC x 2 inch Superseded by part number: 9706716 |
