| 1. | ZA104773 | [2] |
CYLINDER |
IHASSEMBLY - hydraulic, tailgate |
| 2. | 120378 | [8] |
NUT,Hex, 1/2" - 13, Gr 5 |
IHNUT, 1/2"-13, G5 Superseded by part number: 280431 |
| 3. | 444660 | [1] |
DRAIN PLUG,Sq Soc, 3/8"-18 NPTF |
IHPLUG - pipe, square socket, 3/8 inch PT |
| 4. | ZA104995 | [1] |
BASE |
IH- cylinder |
| 5. | ZA104997 | [4] |
ROD |
IH- tie |
| 6. | NSS | [3] |
NOT SOLD SEPARAT |
CONO-RING - cylinder |
| 8. | 851124C1 | [1] |
NUT |
IH- hex lock, 3/4 inch NF Superseded by part number: 131-909 |
| 9. | 812169C1 | [1] |
PISTON |
IH- cylinder Superseded by part number: B17274 |
| 11. | ZA104996 | [1] |
HEAT-EXCHANGER |
IHHEAD - cyllinder |
| 15. | ZA104998 | [1] |
ROD |
IH- piston |
| 16. | 120377 | [1] |
NUT,3/8" - 16, Gr 5 |
IH Superseded by part number: 280136 |
| 17. | T55022 | [1] |
CLEVIS |
CAS- piston rod |
| 18. | 61-33828 | [1] |
HEX SOC SCREW,3/8"-16 x 1 3/4" |
CASBOLT - hex socket head, 3/8 NC x 1-3/4 inch Superseded by part number: 86511683 |
| . . | 812173C1 | [1] |
SEAL KIT |
IHKIT - seal, Includes: Ref. 6, 10, 12, 13 and 14 Superseded by part number: B17231 |
