| 1. | REF | [1] |
INSTRUCTION |
NHCYLINDER ASSEMBLY - twine tube (Cross) (See page 20) |
| 2. | 9402864 | [2] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 1/4"-18, NPTF |
IH- male, 90 degree Superseded by part number: 578384 |
| 3. | 139319C2 | [2] |
BRACKET |
IHHOSE ASSEMBLY - twine tube cylinder, 3/8 ID x 135 inch (10 x 3 429 MM) |
| 4. | ZA105378 | [1] |
FITTING |
CASORIFICE ASSEMBLY - 9/16-18 x 3/4-16 inch, 0.031 inch dia. (0.787 MM) |
| 5. | 570828R1 | [1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro |
IH- 41/64 x 13/16 x 3/32 inch (16 x 21 x 2 MM) Superseded by part number: 128825 |
| 8. | ZA103633 | [1] |
SWITCH |
IH- bale density Superseded by part number: 232773A1 |
| 9. | ZA104562 | [1] |
COVER |
IHASSEMBLY - switch Superseded by part number: 230414A1 |
| 10. | ZA104561 | [1] |
BRACKET |
IH- switch |
| 11. | 120221 | [4] |
NUT,Sl Rnd Hd, #10 - 24 x 1/2" |
IHSCREW - round head slotted, no. 10 NC x 1/2 inch Superseded by part number: 159920 |
| 12. | 221431 | [2] |
WASHER - flat, 5/32 x 3/8 x 1/32 inch (4 x 10 x 1 MM) | |
| 13. | 120217 | [4] |
LOCK WASHER,#10 |
IHWASHER, LOCK, #10 Superseded by part number: 80684 |
| 14. | 26303R1 | [4] |
HARDWARE,#10-24 |
IHNUT - hex, no. 10 NC Superseded by part number: 3062835R1 |
| 15. | 120391 | [2] |
WASHER,#10 |
IH- flat, 7/32 x 1/2 x 1/32 inch (6 x 13 x 1 MM) Superseded by part number: 9824326 |
| 16. | ZA105637 | [1] |
HARNESS |
CAS- baler |
| 17. | ZA105636 | [1] |
HARNESS |
CAS- tractor |
| 18. | 3118918R1 | [1] |
FUSE |
IH- 3 AG, 5 ampere |
| 19. | ZA105839 | [1] |
LIGHT |
CASLAMP ASSEMBLY - full bale |
| 20. | 142450 | [1] |
BULB,C2R, #67, 13.5V |
IH- lamp, no. 67 Superseded by part number: 1094368R1 |
| 21. | 291207C1 | [1] |
CLAMP |
IHSTRAP - tie Superseded by part number: 529070 |
| 22. | ZA104394 | [1] |
BUSHING |
IH- strain relief |
| 23. | 299407C1 | [1] |
CLAMP |
IH- tube Superseded by part number: 86010402 |
