| 1. | 9413979 | [2] |
LOCK NUT,3/8"-16, GC |
IHNUT - hex lock, 3/8 inch NC, grade 8 Superseded by part number: 232-4136 |
| 2. | 21403R1 | [8] |
WASHER |
IH- flat, 13/32 x 1 x 1/8 inch (10 x 25 x 3 MM) Superseded by part number: 87613212 |
| 3. | 96339C1 | [2] |
CAMSHAFT BEARING,0.3752" ID x 1.25" OD x 0.8025" |
IHFOLLOWER - cam. crowned |
| 4. | 24621R1 | [2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 8 |
IH Superseded by part number: 326-636 |
| 5. | 445608 | [2] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5 |
IH- hex, 1/2 NC x 5-1/2 inch Superseded by part number: 88576 |
| 6. | 120378 | [2] |
NUT,Hex, 1/2" - 13, Gr 5 |
IHNUT, 1/2"-13, G5 Superseded by part number: 280431 |
| 7. | ZA104886 | [2] |
SPRING |
IHASSEMBLY - extension |
| 8. | 1281009C1 | [2] |
INSERT |
IH- spring |
| 9. | ZA104672 | [2] |
PIN |
IHASSEMBLY - latch |
| 10. | 17351R1 | [2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2 |
IHBOLT - round head square neck, 3/8 NC x 1 inch, grade 1 Superseded by part number: 88682 |
| 14. | ZA105907 | [1] |
LATCH |
CASASSEMBLY - tailgate |
| 15. | 9413956 | [1] |
LOCK NUT,1/2"-13, GB |
IHNUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138 |
| 16. | ZA104895 | [1] |
CABLE |
IHASSEMBLY - latch |
| 17. | 432-1628 | [8] |
COTTER PIN,1/4" x 1 3/4" |
CASPin, Split (Cotter), 1/4" x 1 3/4" Superseded by part number: 87041 |
| 18. | 62575C1 | [1] |
PIN |
IH- pulley |
| 19. | 1281014C1 | [1] |
PULLEY |
IH- lift |
| 20. | 21957R1 | [1] |
HEADED PIN,5/8" x 2" |
IHPIN - headed, 5/8 x 2 inch Superseded by part number: 439-11032 |
| 21. | 103397 | [1] |
COTTER PIN,5/32" x 1 1/4" |
IHPin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341 |
| 22. | ZA105617 | [1] |
PLATE |
IH- pivot |
| 23. | 22983R1 | [1] |
HEADED PIN,1" x 2" |
CASPIN - headed, 1 x 2 inch |
| 24. | 21214R1 | [2] |
WASHER |
IH- flat, 1-5/32 x 2 x 7/64 inch (29 x 51 x 3 MM) Superseded by part number: 495-81192 |
| 25. | 63196C1 | [1] |
PIN |
IH- clevis Superseded by part number: 427-16400 |
| 26. | REF | [1] |
INSTRUCTION |
NHCYLINDER ASSEMBLY - hydraulic, tailgate (See page 16) |
| 28. | ZA103758 | [1] |
VALVE |
IH- rotary |
| 29. | 610774R1 | [1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 3/8"-18, NPTF |
IHCONNECTOR - 3/8 tube, /16-18 x 3/8 inch PT Superseded by part number: 235534 |
| 30. | 333934R1 | [1] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/8"-18, NPTF |
IH- 90 degrees, 3/8 tube, 9/16-18 x 3/8 inch PT Superseded by part number: 235131 |
| 31. | 147779C1 | [2] |
HYDRAULIC HOSE |
IHHOSE ASSEMBLY - 1/4 ID x 145 inch (6 x 3 683 MM) |
| 32. | M74461 | [2] |
SPACER,26.6mm ID x 33.4mm OD x 19mm L |
IH- 1-3/64 ID x 3/4 inch (27 x 19 MM) |
| 33. | 110928C1 | [1] | |
PPIN - clevis |
| 34. | 299407C1 | [2] |
CLAMP |
IH- tube Superseded by part number: 86010402 |
| 35. | 533959R1 | [3] |
CABLE TIE,.135" x 11" |
IHSTRAP - tie Superseded by part number: 529070 |
| 38. | 1336822C1 | [1] |
ELBOW |
CAS- 90 degrees, 3/8 inch PT |
