| 1. | ZA105687 | [1] |
SHAFT |
CAS- for 26 tooth gear (With lock groove for constant velocity PTO shaft) |
| 2. | 96325C1 | [1] |
OIL SEAL |
IHSEAL - oil Superseded by part number: D53666 |
| 3. | ZA103721 | [1] |
TUBE |
IH- bearing |
| 4. | 536054R1 | [1] |
BEARING CUP,60mm OD x 11.94mm W |
IHCUP - bearing |
| 5. | 96342C1 | [4] |
SHIM |
IH- 0.005 inch (0.127 MM) |
| 5. | 96343C1 | [4] |
SHIM |
IH- 0.020 inch (0.508 MM) |
| 6. | 536053R1 | [2] |
ROLLER BEARING,1.3772" ID x 2.3622" OD x 0.625" |
IHCONE - bearing Superseded by part number: 175507 |
| 7. | 88907 | [2] |
WOODRUFF KEY,#B, 5/16" x 1", HT |
GIKEY - Woodruff, 5/16 x 1 inch (8 x 25 MM) |
| 8. | ZA105434 | [1] |
GEAR |
CAS- 26 tooth, forged |
| 9. | 618023R91 | [2] |
BEARING ASSY,34.93mm ID x 18.2mm W |
IHCONE - bearing |
| 10. | ZA103720 | [1] |
BOX |
IHHOUSING ASSEMBLY - gearbox |
| 11. | 618024R1 | [1] |
BEARING CUP,65.113mm OD x 13.97mm W |
IH Superseded by part number: 86516467 |
| 12. | 96344C1 | [2] |
SHIM |
IH- 0.005 inch (0.127 MM) |
| 12. | 96345C1 | [1] |
SHIM |
IH- 0.020 inch (0.508 MM) |
| 13. | 9617020 | [1] |
PLUG,1/4" - 18 x 0.48" |
NH- pipe, Hex Socket, 1/4 inch PT |
| 16. | ZA104574 | [1] |
WASHER |
IH- chamfered |
| 17. | 20969R1 | [1] |
PLUG |
IH- pipe, square head, 3/4 inch PT Superseded by part number: 221-48 |
| 18. | 103409 | [1] |
PIN, SPLIT (COTTER),3/16" x 1 1/2" |
IH Superseded by part number: 20328R1 |
| 19. | 427640 | [1] |
SLOTTED NUT,3/4"-16, G5 |
IHNUT - hex slotted, 3/4 inch NF Superseded by part number: 129-290 |
| 20. | 26512R1 | [1] |
WASHER |
IH- flat, 25/32 x 2 x 11/64 inch (20 x 51 x 4 MM) Superseded by part number: 86624159 |
| 21. | ZA105433 | [1] |
GEAR |
CAS- 19 tooth, forged |
| 22. | ZA105688 | [1] |
SHAFT |
CAS- for 19 tooth gear (With lock groove for constant velocity PTO shaft) |
| 23. | ZA103722 | [1] |
HOUSING |
IHTUBE - bearing |
| 26. | 96324C1 | [1] |
OIL SEAL |
IHSEAL - oil |
| 27. | 180177 | [8] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5 |
IH- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410 |
| 28. | ZA103653 | [1] |
PLUG |
IH- breather (Replaces 651616R1) |
| 29. | NSS | [1] |
NOT SOLD SEPARAT |
CONPLUG - breather (Order ZA103653) |
| 30. | 27327R1 | [1] |
BUSHING - pipe, 1/2 PT x 3/4 inch PT | |
