| . . | 24100J3295F7 | [1] | CONTROL ASSY | |
| 6. | 2416P4545 | [2] | STAND, CONTROL | STAND, CONTROL |
| 7. | 2405U101D0808 | [6] | BUSHING | KOB |
| 8. | 2406T1395 | [2] | LEVER | KOB |
| 9. | 2406T1396 | [4] | LINK | LINK |
| 12. | ZP45X12030 | [6] | PIN | KOB |
| 13. | 2419T1862D3 | [2] | PIN | KOB |
| 14. | 2419T1862D2 | [2] | PIN | KOB |
| 17. | 2406T1385 | [4] | YOKE | KOB Superseded by part number: 2406T2278 |
| 18. | 2419R9D2 | [4] | COTTER PIN | KOBOD 08mm x 27.7mm Long |
| 19. | 2419R9D4 | [1] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 20. | ZM11C10030 | [4] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher) |
| 21. | ZM11C10025 | [8] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 22. | 2406T1027 | [2] | LEVER | KOB |
| 23. | ZN16C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 21. | ZW16X12000 | [6] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 25. | ZN16C12010 | [10] | NUT | KOB Superseded by part number: ZN18C12010 |
| 26. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 29. | 2419T2865 | [1] | PIN PIN, Serial Range: LP0601-870 | PIN PIN, Serial Range: LP0601-870 |
| . . | 2419T3658 | [1] | PIN, Start Serial: LP0871 | PIN, Start Serial: LP0871 |
| 30. | 2406P2065D1 | [1] | BALL, LEVER GRIP | BALL, LEVER GRIP |
| 31. | 2406P2065D2 | [1] | LEVER | KOBGRIP Superseded by part number: 2406P2065D5 |
| 33. | 2406R176D13 | [1] | CABLE | KOBCABLE, CONTROL |
| 34. | 2436R176D14 | [1] | CABLE,CONTROL | |
| 35. | 24100X1124F2 | [1] | REMOTE-CONTR0L ASSY SEE FIG:03-007, Serial Range: LP0601-858 | |
| . . | 24100X1124F3 | [1] | REMOTE-CONTROL ASSY SEE FIG:03-007, Start Serial: LP0859 | |
| 38. | 2406T1644 | [1] | PLATE | PLATE |
| . . | 2406T1643 | [1] | PLATE | PLATE |
| 40. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 41. | 24100N1760F4 | [1] | LEVER ASSY, CONTROL | |
| 41-1. | 2406P1990D1 | [1] | LINK | LINK |
| 41-2. | 2406P1990D2 | [1] | LINK | LINK |
| 41-3. | 2406P1991 | [2] | LEVER, CONTROL | LEVER, CONTROL |
| 41-6. | 2432T1305 | [2] | CLAMP | KOB |
| 41-7. | ZS16C10050 | [4] | CAPSCREW M10x1.50x50mm | CAPSCREW M10x1.50x50mm |
| 41-8. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 41-9. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW M10x1.50x30mm Superseded by part number: ZS18C10030 |
| 41-10. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 41-11. | 4019T12 | [1] | PIN | KOB |
| 41-12. | 4016P16 | [1] | BRACKET | KOB |
| 41-13. | 4018T20 | [2] | SPACER | KOB |
| 41-14. | 4025Z8 | [4] | NEEDLE BEARING | KOB |
| 41-15. | 4045Z8 | [4] | OIL SEAL | KOB |
| 41-16. | 6Z1 | [2] | LEVER | KOB |
| 41-17. | 3611V012 | [1] | WASHER | KOB |
| 41-18. | ZP15D05065 | [1] | COTTER PIN | KOB |
| 41-26. | 2406P2816D1 | [1] | PEDAL | PEDAL |
| 41-27. | 2406P2816D2 | [1] | PEDAL | PEDAL |
