| . . | 24100J5073F1 | [1] | CONTROL ASSY-, Start Serial: 1392 | |
| . . | 24100J5073F7 | [1] | CONTROL ASSY | |
| 1. | 24100X1124F4 | [1] | REMOTE-CONTROL ASSY P.101-01, Start Serial: 1392 | |
| 2. | 2419T3658 | [1] | PIN | PIN |
| 3. | 24100N1839F4 | [1] | LEVER ASSY, CONTROL | |
| 3-3. | 4019T12 | [1] | PIN | KOB |
| 3-4. | 4016P16 | [1] | BRACKET | KOB |
| 3-5. | 4018T20 | [2] | SPACER | KOB |
| 3-6. | 4025Z8 | [4] | NEEDLE BEARING | KOBROLLER |
| 3-7. | 4045Z8 | [4] | OIL SEAL | KOB |
| 3-8. | 6Z1 | [2] | LEVER | KOB |
| 3-9. | 3611V012 | [1] | WASHER | KOB |
| 3-10. | ZP15D05065 | [1] | COTTER PIN | KOB |
| 3-15. | 2406P2497D1 | [1] | LEVER, CONTROL | LEVER, CONTROL |
| 3-16. | 2406P2497D2 | [1] | LEVER, CONTROL | |
| 4. | 2406P2065D1 | [1] | BALL, LEVER GRIP | BALL, LEVER GRIP |
| 5. | 2406P2065D2 | [1] | LEVER | KOBGRIP Superseded by part number: 2406P2065D5 |
| 6. | 2416P4545D2 | [2] | STAND, CONTROL | |
| 7. | 2405U101D1208 | [6] | BUSHING | KOB |
| 8. | 2406T1670 | [2] | LEVER | KOB |
| 9. | 2406T1675 | [4] | LINK | KOB |
| 10. | 2406T1644 | [1] | PLATE | PLATE |
| 11. | 2406T1643 | [1] | PLATE | PLATE |
| 12. | 2419T3642D1 | [6] | PIN | KOB, Start Serial: 159 Superseded by part number: 2419T3784D1 |
| 13. | 2419T3642D2 | [2] | PIN, Start Serial: 159 | PIN, Start Serial: 159 |
| 14. | 2419T3644D1 | [2] | PIN, Start Serial: 159 | PIN, Start Serial: 159 |
| 15. | 2406R223D3 | [1] | FLEXIBLE CONTROL | KOB |
| 16. | 2406R223D1 | [1] | FLEXIBLE CONTROL | KOB |
| 17. | 2406T1672 | [4] | YOKE | KOB Superseded by part number: 2406T2278 |
| 18. | 2419R9D2 | [2] | COTTER PIN | KOBOD 08mm x 27.7mm Long |
| 19. | 2419R9D4 | [8] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 20. | ZM11C10030 | [4] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher) |
| 21. | ZM11C10025 | [8] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 22. | 2406T1027 | [2] | LEVER | KOB |
| 23. | ZN16C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 24. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 25. | ZN16C12010 | [2] | NUT | KOB Superseded by part number: ZN18C12010 |
| 26. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 27. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 34. | 2414T2053 | [2] | COVER | KOB |
| 35. | 2414T2052 | [2] | COVER | COVER |
| 36. | 2414R230 | [2] | BOOT | KOB |
| 39. | 24100X1124F5 | [1] | REMOTE-CONTROL ASSY P. 101-01 | |
| 41. | 2419T3784D1 | [6] | PIN | KOB |
| 42. | 2419T3784D2 | [2] | PIN | KOB |
| 43. | 2419T3790D1 | [2] | PIN | KOB |
