Pos.	Part No	Qty	Parts name	Comments
. .	24100N5355F9	[1]	TOOL & ACCESSOR	TOOL & ACCESSOR
10.	ZT31B13250	[1]	HANDLE	KOB
11.	ZT31D13150	[1]	BAR	KOB
12.	ZT31A24000	[1]	SOCKET	KOB
13.	ZT31A22000	[1]	SOCKET	KOB
14.	ZT31A19000	[1]	SOCKET	KOB
15.	ZT31A17000	[1]	SOCKET	KOB
16.	ZT22A14000	[1]	KEY	KOB14mm
17.	ZT22A12000	[1]	KEY, SCREW 12mm	KEY, SCREW 12mm
18.	ZT22A08000	[1]	KEY	KOBScrew -- 08mm
19.	ZT22A06000	[1]	KEY, SCREW 06mm	KEY, SCREW 06mm
21.	ZT12D20000	[1]	WRENCH, ADJUST 24mm Maximum	WRENCH, ADJUST 24mm Maximum
22.	2421T8	[1]	TIGHTENER	KOB
23.	ZT71A15000	[1]	HAMMER	KOB
24.	2414T4185	[1]	TOOL BOX	KOB400x155x110mm
26.	ZT51A15000	[1]	PLIERS	KOB
27.	2421R170	[1]	GENERAL TOOL	KOB Superseded by part number: YW01T01014P1
28.	2421R140	[1]	NOZZLE	KOBAdapter -- 1/8"PFx180mm Long
29.	2421Z298	[1]	CAP	KOB
30.	ZT22A10000	[1]	KEY	KOB10mm
31.	B16T0442D1	[5]	SHIM,130mm OD x 72mm ID x 1.2mm Thk	KOBID 72 x OD 130 x Th 1.2mm
32.	B16T0442D2	[3]	SHIM,130mm OD x 72mm ID x 1.6mm Thk	KOBID 72 x OD 130 x Th 1.6mm
33.	B16T0442D29	[3]	SHIM,130mm OD x 72mm ID x 2.0mm Thk	KOBID 72 x OD 130 x Th 2.0mm
34.	B16T0442D5	[1]	SHIM,130mm OD x 72mm ID x 2.3mm Thk	KOBID 72 x OD 130 x Th 2.3mm
35.	B16T0442D27	[1]	SHIM,62mm ID x 100mm OD x 1.2mm Thk	KOBID 62 x OD 100 x Th 1.2mm
36.	B16T0442D19	[1]	SHIM,62mm ID x 100mm OD x 1.6mm Thk	KOBID 62 x OD 100 x Th 1.6mm
37.	B16T0442D30	[1]	SHIM,100mm OD x 62mm ID x 2.0mm Thk	KOBID 62 x OD 100 x Th 2.0mm
38.	B16T0442D20	[1]	SHIM,100mm OD x 62mm ID x 2.3mm Thk	KOBID 62 x OD 100 x Th 2.3mm
39.	2418T4037D2	[1]	SHIM,67mm ID x 110mm OD x 1.2mm thk	KOBID 67x OD 110 x Th 1.2mm
40.	2418T4037D1	[1]	SHIM,67mm ID x 110mm OD x 2.3mm thk	KOBID 67x OD 110 x Th 2.3mm
41.	ZT13A50000	[1]	BOX SPANNER	KOB
42.	ZT13A41000	[1]	BOX SPANNER	KOB
43.	ZT13A36000	[2]	BOX SPANNER	KOB
44.	ZT13A24000	[1]	HEATER	KOB
45.	ZT13A19000	[1]	HEATER	KOB
46.	ZT13A17000	[1]	SPANNER	SPANNER
47.	ZT13A14000	[1]	SPANNER	SPANNER
48.	ZT13A10000	[1]	SPANNER	SPANNER
49.	ZT42A06100	[1]	DRIVER	DRIVER
50.	ZT42B30150	[1]	DOG	KOB
52.	2421R154	[1]	GREASE GUN	KOB Superseded by part number: EAPN17125A
