| . . | 2438U706F1 | [1] | CYLINDER ASSY | |
| 1. | 2438U706S1 | [1] | TUBE, CYLINDER | |
| 2. | 2438U706S2 | [1] | PISTON-ROD | |
| 3. | 2438U706S3 | [1] | PISTON | |
| 4. | 24838U25S7 | [2] | RING, WEAR | |
| 5. | 2438U706S5 | [1] | O-RING | KOB |
| 6. | 2438U706S6 | [1] | SEAL | KOB |
| 8. | ZS73C08020 | [1] | SETSCREW | |
| 9. | ZD12G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 10. | ZD75G11000 | [2] | RING | KOBBACK-UP |
| 11. | 2438U706S11 | [1] | COVER | |
| 12. | R45P0050D4 | [1] | SEAL | KOB |
| 13. | R45P0051D7 | [1] | O-RING | KOB |
| 14. | 2438U706S14 | [1] | O-RING | KOB Superseded by part number: ZD12G15000 |
| 15. | 2438U352S10 | [1] | KIT | KOB Superseded by part number: 2418U130D27 |
| 16. | 2438U706S16 | [1] | SEAL, DUST | |
| 17. | 2438U706S17 | [1] | RING, RETAINER | |
| 18. | 2438U706S18 | [1] | O-RING | |
| 19. | 2438U706S19 | [1] | RING, BACK-UP | |
| 20. | 2438U352S16 | [1] | RING, RETAINER | |
| 21. | 2438U434S12 | [1] | BUSHING | |
| 22. | 2438U706S22 | [1] | COVER | |
| 23. | 2438U588S24 | [1] | DUST CAP | KOBSEAL, DUST Superseded by part number: 2438U368S16 |
| 24. | 24838U25S16 | [1] | RING, RETAINER | |
| 25. | 24838U24S11 | [1] | PACKING | PACKING |
| 26. | 2438U706S26 | [1] | BUSHING | |
| 27. | ZD12G14500 | [1] | O-RING,144.40mm ID x 150.60mm OD x 3.10mm | KOBID 144.40 ± 1.16 x OD 150mm |
| 28. | 2438U706S28 | [1] | RING, BACK-UP | |
| 29. | ZD12P14000 | [1] | O-RING | KOB |
| 30. | 45Z91D117 | [1] | O-RING | KOB |
| 31. | R45P0050D11 | [1] | SEAL | KOB |
| 32. | 2438U706S32 | [1] | BUSHING | |
| 33. | 2438U282S23 | [1] | SNAP RING | KOB |
| 34. | 2438U706S34 | [1] | BUSHING | |
| . . | 2438U706R100 | [1] | REPAIR KIT, INCLUDE 12 TO 16, 19, 23, 25 & 27 TO 31 | |
| . . | 2438U706R110 | [1] | REPAIR KIT, INCLUDE 14 TO 16, 19 & 10 | |
