| . . | 2441U789F1 | [1] | HYDRAULIC MOTOR | KOB(SWING) |
| . . | 2441U789F2 | [1] | HYDRAULIC MOTOR | KOB(SWING) |
| 11. | 2441U789S11 | [9] | PISTON ASSY CONSISTS OF REF 121,122 | PISTON ASSY CONSISTS OF REF 121,122 |
| 15. | 2441U789S15 | [1] | COVER ASSY,VALVE (FOR F2 ONLY)CONSISTS OF REF 303,451 | |
| 20. | 2441U789S20 | [1] | COVER ASSY,VALVE (FOR F1 ONLY) CONSISTS OF REF 303,451 | |
| 50. | 2441U789S50 | [1] | CYLINDER | KOB(FOR F2 ONLY) Superseded by part number: 2441U825S111 |
| 70. | 2441U789S70 | [1] | CASING(FOR F2 ONLY) | |
| 101. | 2441U789S101 | [1] | SHAFT | KOB |
| 106. | 2441U789S106 | [1] | SPACER | KOB |
| 111. | 2441U789S111 | [1] | CYLINDER(FOR F1 ONLY) | |
| 113. | 2441U789S113 | [1] | BUSHING | KOB |
| 114. | 2441U789S114 | [1] | SPRING | KOB |
| 116. | 2441U789S116 | [12] | PUSH ROD | KOB |
| 117. | 2441U789S117 | [2] | SPACER | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | 2441U789S123 | [1] | PLATE | KOB |
| 124. | 2441U789S124 | [1] | PLATE | KOBSHOE |
| 131. | 2441U789S131 | [1] | EXCHANGE VALVE PLATE | KOB |
| 301. | 2441U789S301 | [1] | CASING(FOR F1 ONLY) | |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER,VALVE |
| 304. | 2441U789S304 | [1] | COVER | KOBFRONT |
| 401. | ZS23C16035 | [4] | SCREW,Hex Socket Head, M16 x 35mm | KOBM16x2.0x35mm |
| 432. | ZR16X03500 | [2] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 433. | 2436U1318S836 | [1] | RING | KOBSNAP |
| 437. | ZR26X08000 | [1] | SNAP RING | KOBRetaining -- ID 80 x OD 85.5 x Th 2.5mm |
| 438. | ZR26X04200 | [1] | RETAINER | KOBRING,LOCKING |
| 443. | 2441U789S443 | [1] | BEARING, BALL | BEARING, BALL |
| 444. | 2441U789S444 | [1] | ROLLER BEARING | KOBBALL Superseded by part number: YX15V00004S010 |
| 451. | ZP26D05012 | [2] | PIN | KOBSpring |
| 464. | 2441U667S466 | [1] | PLUG | KOB1/4" PF |
| 471. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 472. | 2441U789S472 | [1] | O-RING | KOB Superseded by part number: 2441U825S472 |
| 485. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 491. | 2441U564S491 | [1] | OIL SEAL | KOB |
| 702. | 2441U789S702 | [1] | PISTON | KOBBRAKE(FOR F2 ONLY) |
| 706. | 2441U789S706 | [1] | O-RING | KOB(FOR F2 ONLY) Superseded by part number: 2441U825S706 |
| 707. | 2415U188S706 | [1] | O-RING | KOB(FOR F2 ONLY) |
| 712. | 2441U789S712 | [20] | SPRING | KOB(FOR F2 ONLY) |
| 742. | 2441U789S742 | [2] | PLATE | KOB(FOR F2 ONLY) |
| 743. | 2441U789S743 | [3] | PLATE | KOB(FOR F2 ONLY) |
| 992. | ZE82T08000 | [2] | PLUG | KOB1/2" PT |
