神钢零件查询(K903) - MARK II EXCAVATOR ASN LE7872 (1/88-12/03) (11-028) - MOTOR ASSY-PROPELLING Kobelco

作者：广数供应链运营团队

浏览数：

时间：2025-01-23 23:09:08

工程机械零件图册查询

Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴

Pos.	Part No	Qty	Parts name	Comments
. .	2441U532F1	[1]	HYDRAULIC MOTOR	KOBASSY (PROPELLING)
1.	2441U532S1	[1]	HUB	HUB
2.	NSS	[1]	NOT SOLD SEPARAT	CONSPINDLE
3.	NSS	[1]	NOT SOLD SEPARAT	CONFLANGE
4.	NSS	[1]	NOT SOLD SEPARAT	CONGEAR
5.	NSS	[1]	NOT SOLD SEPARAT	CONGEAR
6.	2441U532S6	[1]	GEAR	KOB
7.	2441U532S7	[3]	GEAR	GEAR
8.	2441U532S8	[1]	COVER	COVER
9.	NSS	[3]	NOT SOLD SEPARAT	CONCRANK-SHAFT
10.	2441U532S10	[1]	REPAIR KIT	KOB Superseded by part number: YR15V00002R400
11.	2441U532S11	[3]	COLLAR	KOB
12.	2441U532S12	[6]	PIN	KOB
13.	2441U532S13	[1]	RING	KOB
14.	NSS	[3]	NOT SOLD SEPARAT	CONBOLT,REAMER
15.	2441U532S15	[2]	BALL BEARING	KOB
16.	NSS	[6]	NOT SOLD SEPARAT	CONROLLER BEARING,TAPER
17.	NSS	[6]	NOT SOLD SEPARAT	CONBEARING,NEEDLE
18.	ZR16X02500	[3]	RING	KOBRetaining -- ID 23.2 x OD 25 x Th 1.2mm
19.	2441U532S19	[3]	RING	KOB
20.	ZR16X01900	[1]	SNAP RING	KOB
21.	ZD12G23000	[1]	O-RING,229.30mm ID x 240.70mm OD x 5.70mm	KOB
22.	2441U532S22	[1]	O-RING	KOB
23.	2441U532S23	[1]	O-RING	KOB
24.	2441U532S24	[1]	REPAIR KIT	KOB Superseded by part number: YR15V00002R400
25.	2441U532S25	[2]	PLUG	KOB
26.	ZD12P00600	[1]	O-RING	KOBID 05.80 ± 0.15 x OD 09mm
101.	NSS	[1]	NOT SOLD SEPARAT	CONFLANGE
102.	2441U532S102	[1]	SHAFT	KOB
103.	2441U532S103	[1]	PLATE	PLATE
104.	2441U532S104	[1]	PLANETARY CARRIER SHAFT CYLINDER BLOCK	PLANETARY CARRIER SHAFT CYLINDER BLOCK
105.	NSS	[9]	NOT SOLD SEPARAT	CONPISTON
106.	NSS	[9]	NOT SOLD SEPARAT	CONSHOE
107.	2441U532S107	[1]	PLATE	KOB
108.	2441U532S108	[1]	SPARE PART	HIT Superseded by part number: 2441U815S108
109.	2441U532S109	[1]	PLATE	HIT
110.	2441U532S110	[2]	WASHER	KOB
111.	2441U532S111	[1]	SPACER	KOB
112.	2441U532S112	[1]	MANIFOLD PISTON	MANIFOLD PISTON
113.	2441U532S113	[8]	SPRING	KOB
114.	2441U532S114	[1]	SPRING	KOB
115.	2441U532S115	[2]	PLATE	KOBDISK
116.	2441U532S116	[2]	PLATE	KOBFRICTION
117.	2441U532S117	[1]	PIN	PIN
118.	2441U532S118	[1]	VALVE SEAT	KOBSEAT, VALVE
119.	2441U532S119	[1]	HYDRAULIC VALVE	KOB
120.	2441U532S120	[1]	SPRING	KOB
121.	2441U496S53	[1]	RING	KOB
122.	NSS	[1]	NOT SOLD SEPARAT	CONSPOOL
123.	2441U532S123	[2]	PLUG	KOB
124.	2441U532S124	[2]	RETAINER	RETAINER
125.	2441U532S125	[2]	PLUG	KOB
126.	2441U532S126	[2]	HYDRAULIC VALVE	KOB
127.	2441U532S127	[2]	SPRING	KOB
128.	2441U532S128	[2]	SPRING	KOB
129.	2441U532S129	[1]	BEARING	KOB
130.	2441U532S130	[1]	BEARING	KOB
131.	2441U532S131	[1]	OIL SEAL	KOB
133.	2441U532S133	[1]	O-RING	KOB
134.	ZD12G14000	[1]	O-RING,139.40mm ID x 145.60mm OD x 3.10mm	KOBID 139.40 ± 1.12 x OD 145mm
135.	ZD12P00900	[1]	O-RING	KOBID 08.80 ± 0.17 x OD 12mm
136.	ZD12P01600	[2]	O-RING	KOBID 15.80 ± 0.20 x OD 20mm
137.	ZD12P02600	[2]	O-RING	KOBID 25.70 ± 0.26 x OD 32mm
138.	2441U532S138	[1]	RING,RETAINER
139.	2441U532S139	[2]	PIN
140.	2441U532S140	[2]	PIN
141.	2441U532S141	[3]	ROLLER	KOB
143.	ZS23C10030	[6]	SCREW,Hex Socket Head, M10 x 30mm	KOBM10x1.50x30mm Superseded by part number: ZS28C10030
144.	2441U496S47	[1]	PLUG	KOBPLUG
146.	ZD12P01400	[1]	O-RING	KOBID 13.80 ± 0.19 x OD 18mm
148.	2441U532S148	[2]	SPRING
149.	2441U532S149	[1]	BACK-UP RING	KOB
150.	2441U532S150	[1]	BACK-UP RING	KOB
. .	2441U532R100	[1]	REPAIR KIT	KOBREPAIR KIT CONSISTS OF REF 2,3 & 14
. .	2441U532R200	[1]	REPAIR KIT	KOBCONSISTS OF REF 4,5,9,16 & 17
. .	2441U532R300	[1]	REPAIR KIT CONSISTS OF REF 101 & 122	REPAIR KIT CONSISTS OF REF 101 & 122
. .	2441U532R400	[1]	REPAIR KIT	KOBCONSISTS OF REF 105 & 106
. .	2441UR500	[1]	REPAIR KIT CONSISTS OF REF 21-24,26 & 131 133-137,146,149,150	REPAIR KIT CONSISTS OF REF 21-24,26 & 131 133-137,146,149,150
