| . . | 2438U693F1 | [1] | CYLINDER ASSY | |
| . . | 2438U693F2 | [1] | CYLINDER | KOBASSY |
| 1. | 2438U693S1 | [1] | TUBE,CYLINDER,(FOR F1 ONLY) | |
| 2. | 2438U696S7 | [2] | BUSHING | KOB |
| 3. | 2438U693S3 | [1] | PISTON ROD | KOB |
| 4. | 2438U693S4 | [1] | PISTON | |
| 5. | 2438U693S5 | [1] | SEAL | |
| 6. | 2438U693S6 | [2] | WEAR RING | KOB |
| 7. | ZD12P03500 | [1] | O-RING | KOB |
| 8. | 2438U673S11 | [1] | NUT | KOB |
| 9. | ZP26D06045 | [1] | ROLL PIN | KOBPIN SPRING |
| 10. | 2438U693S10 | [1] | COVER.ROD | |
| 11. | 2438U673S16 | [1] | BUSHING | KOB Superseded by part number: R25N0003D3 |
| 12. | ZD12P08000 | [1] | O-RING | KOBID 79.60 ± 0.69 x OD 92mm |
| 13. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.73 x OD 90mm |
| 14. | 2438U692S16 | [1] | PACKING, ROD | |
| 15. | 2438U692S20 | [1] | SEAL | KOB |
| 16. | 2438U673S20 | [1] | CLIP | KOBRING, RETAINER |
| 17. | 2438U693S17 | [4] | DUST CAP | KOBSMAL |
| 18. | 2438U693S18 | [1] | TUBE CYLINDER,FOR F2 ONLY) | |
| . . | 2438U693R100 | [1] | REPAIR KIT | KOBCONSISTS OF THE REF 12 TO 15 |
| . . | 2438U693R110 | [1] | REPAIR KIT | KOBCONSISTS OF THE REF 5 TO 7 |
