| . . | 2437U201F1 | [1] | HYDRAULIC PUMP | KOBASSY |
| 1. | 2410R162F1 | [1] | SHAFT ASSY (F) ,SEE FIG(11-002) | |
| 2. | 2410R161F1 | [1] | SHAFT ASSY ® ,SEE FIG(11-001) | |
| 3. | 24100R166F1 | [2] | ROTARY DIVIDER | KOBROTARY ASSY ,SEE FIG(11-034) |
| 4. | 2439R61F1 | [2] | PISTON ASSY ,SEE FIG(11-027) | |
| 5. | 2416R252F1 | [2] | HANGER ASSY ,SEE FIG(11-005) | |
| 6. | 2414R268F1 | [1] | COVER | KOBCOVER ASSY ,SEE FIG(11-003) |
| 7. | 2480U265F1 | [1] | CONTROLLER ASSY (F), SEE FIG(11-032) | |
| 8. | 2480U194F1 | [1] | CONTROLLER ASSY (R), SEE FIG(11-031) | |
| 11. | 2432R231F1 | [1] | NAME-PLATE ASSY | |
| 11-1. | 2432R231S1 | [1] | NAME-PLATE | |
| 11-2. | 2441U661S18 | [1] | NAME-PLATE | |
| 11-3. | 2436U1000S30 | [4] | SCREW | KOBCAP |
| 20. | 2437U201S20 | [1] | HOUSING (F) | |
| 21. | 2437U201S21 | [1] | HOUSING (R) | |
| 22. | 2437U201S22 | [1] | COUPLING | |
| 23. | 2437U201S23 | [2] | PIECE | |
| 27. | 2437U201S27 | [2] | O-RING | KOB |
| 28. | ZD11P01800 | [1] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 29. | 24100U448S6 | [1] | PLUG | |
| 34. | 2418R244F1 | [1] | PLATE ASSY,SEE FIG (11-006) | |
