| 1. | YN64H01319P1 | [1] | BRACKET | KOBBracket Superseded by part number: YN64H01372P1 |
| 2. | YN35V00010F2 | [1] | VALVE | KOBSolenoid, See Figure 08-24 |
| 3. | LC35V00004F2 | [1] | SOLENOID VALVE | KOBSee Figure 08-15 |
| 4. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 5. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 6. | 2420R349D072 | [2] | FLEXIBLE HOSE | SM720mm Long (28-11/32 in) Superseded by part number: 24820R63D072 |
| 7. | 2420R349D045 | [1] | HOSE | KOB450mm Long (17-23/32 in) |
| 8. | 2444R963D30 | [1] | HOSE | KOB280mm Long (11-1/32 in) Superseded by part number: 2444R963D32 |
| 9. | 2420R349D028 | [1] | HOSE,280.00 mm | KOB Superseded by part number: 2420R349D030 |
| 11. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH52X04000), SAE No. 4-1, Not Shown Superseded by part number: 165202, 72186131 |
| 12. | ZH42X04000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 13. | ZH32X04000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 14. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 15. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2525), ID 10.8mm x OD 13.2mm, Not Shown |
| 16. | HH35X04004G3 | [2] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 17. | 2444Z3421 | [1] | TEE | KOB(2) 3/8"PFx1/4"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z3421), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| 18. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| . . | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CAS(Part of ZH32X04006), SAE No. 6-1, Not Shown Superseded by part number: 9617873 |
| 19. | PW64H01011P1 | [1] | TEE | KOB1/4"PFx(2)3/8"PFx 66mm Long (Incls. O-Ring ZD12P01400) |
| 20. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| 21. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 22. | ZW16H06000 | [2] | WASHER | KOBID 06 x OD 15 x Th 3.2mm |
| 23. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 24. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 25. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 26. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 27. | 2444Z3421 | [1] | TEE | KOB(2) 3/8"PFx1/4"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 28. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
