| 1. | LC35V00004F2 | [2] | SOLENOID VALVE | KOBSee Figure 08-15 |
| 2. | ZS18C10016 | [4] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm, Not Shown |
| 3. | ZW22X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm, Not Shown Superseded by part number: ZW26X10000 |
| 4. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 5. | ZH32X04000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH32X04000), SAE No. 4-1, Not Shown Superseded by part number: 165202, 72186131 |
| 6. | 2444Z2337 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2337), ID 10.8mm x OD 13.2mm, Not Shown |
| 7. | HH55Q04004G1 | [3] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 8. | ZH22X04000 | [11] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| 9. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 10. | 2444Z2338 | [1] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 11. | 2444P1171D4 | [1] | HYD CONNECTOR | SM1/4" PF - 1/4" PF x 80mm (3-9/64 in) (Incls. O-Ring ZD12P01100) |
| 20. | YM68HU1006P1 | [1] | Block | |
| 21. | 2444Z3820 | [1] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100), Not Shown |
| 22. | 2479U2058 | [1] | PRESSURE SWITCH | KOB |
| 23. | YX52S00010P1 | [2] | SENSOR | KOBPressure (PF 1/4) Superseded by part number: LC52S00019P1 |
| 24. | 2444Z3785 | [2] | HYD CONNECTOR | KOB1/4" PT (Incls. O-Ring ZD12P01100) |
| 25. | ZS18C08060 | [2] | SCREW,Hex, M8 x 60mm | KOBM08x1.25x60mm |
| 26. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 27. | 2425Z519 | [1] | BALL | KOB |
| 28. | 2444Z3756 | [1] | HYD CONNECTOR | KOB1/4" PT (Incls. 2 - O-Rings ZD12P01100) |
| 29. | 2444Z3520 | [1] | TEE | KOB1/4" PT - 1/4" PT - 1/8" PT (All female) |
| 30. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z2359), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| 31. | 2420Z2185 | [1] | GROMMET | KOBNot Shown |
| 32. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long, Not Shown |
| 33. | PY01P01043D2 | [2] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
| 34. | 2420R349D220 | [1] | HOSE,2200.00 mm | KOB Superseded by part number: HX21E04220DX |
| 35. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 36. | 2444R1119D040 | [1] | HOSE,400.00 mm | KOB |
| 37. | 2420R349D230 | [1] | HOSE ASSY. | KOB2300mm Long (90-1/2 in) |
| 38. | 2420R349D120 | [2] | HOSE,6.35mm ID x 1200mm L | KOB |
| 39. | 2444R963D1 | [1] | FLEXIBLE HOSE | KOB750mm Long (29-1/2 in) |
| 40. | 2444R1119D280 | [1] | HOSE | KOB2800mm Long (110-1/4 in) |
| 41. | HX31E06060DX | [1] | Hose -- 600mm Long (23-5/8 in) | |
| 42. | 2444R963D42 | [1] | HOSE ASSY 2800mm Long (110-1/4 in) | HOSE ASSY 2800mm Long (110-1/4 in) |
| 43. | 2444R963D1 | [1] | FLEXIBLE HOSE | KOB750mm Long (29-1/2 in) |
| 44. | 2444R963D38 | [1] | FLEXIBLE HOSE | KOB1100mm Long (43-19/64 in) |
| 45. | 2444R963D25 | [1] | FLEXIBLE HOSE | KOBHOSE 3000 mm long (118-7/64 in) |
| 46. | 2444R963D8 | [1] | HOSE | KOB |
| 47. | 2444R963D19 | [1] | FLEXIBLE HOSE | HIT1500 mm long (59-3/64 in) |
| 48. | 2444Z3783 | [2] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100), Not Shown |
| 49. | YM68HU1008P1 | [1] | Bracket | |
| 50. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm, Not Shown |
| 51. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm, Not Shown |
| 52. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm, Not Shown |
