| 1. | ZG23F16016 | [4] | HYD CONNECTOR | KOB1.0"-1.0" PT (Incls. O-Ring 237-6016) |
| . . | 237-6016 | [1] | O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro | CAS(Part of ZG23F16016), SAE No. 16-1, Not Shown Superseded by part number: 72186238, 167268 |
| 2. | YM19HU1004P1 | [2] | HYD CONNECTOR | KOB(Incls. O-Rings ZD12P01800 & YM19HU1006P1) |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of YM19HU1004P1), ID 17.8mm x OD 20.2mm, Not Shown |
| . . | YM19HU1006P1 | [1] | O-RING,12.42mm ID x 1.78mm Width | KOB(Part of YM19HU1004P1), ID 12.42 ± 0.13 x OD 16mm, Not Shown |
| 3. | YM19HU1005P1 | [4] | HYD CONNECTOR | KOB(Incls. O-Rings ZD12P01400 & YM19HU1003P1) Superseded by part number: 84600280 |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of YM19HU1005P1), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| . . | YM19HU1003P1 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOB(Part of YM19HU1005P1), ID 09.25 ± 0.13 x OD 12.81mm, Not Shown Superseded by part number: 9993141 |
| 4. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH22X04000), SAE No. 4-1, Not Shown Superseded by part number: 165202, 72186131 |
| 5. | ZH52X08000 | [1] | TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring | KOB(Incls. O-Ring 237-6008) |
| . . | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CAS(Part of ZH52X08000), SAE No. 8-1, Not Shown Superseded by part number: 128825 |
| 6. | ZD12A02100 | [4] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
