| 1. | HH25R08008G1 | [1] | HYD CONNECTOR | KOB1/2" PF (Incls. O-Ring ZD12P01800) 106mm Long |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of HH25R08008G1), ID 17.8mm x OD 20.2mm, Not Shown |
| 2. | HG33F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long |
| . . | ZD12P02900 | [1] | O-RING | KOB(Part of HG33F10016G1), ID 28.70 ± 0.29 x OD 35mm, Not Shown |
| 3. | HG34F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 100mm Long |
| 4. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 5. | ZH42X08000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6008) |
| . . | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CAS(Part of ZH42X08000), SAE No. 8-1, Not Shown Superseded by part number: 128825 |
| 6. | YM19HU1001P1 | [3] | ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & YM19HU1003P1) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of YM19HU1001P1), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| . . | YM19HU1003P1 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOB(Part of YM19HU1001P1), ID 09.25 ± 0.13 x OD 12.81mm, Not Shown Superseded by part number: 9993141 |
| 7. | YM19HU1002P1 | [1] | ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & YM19HU1006P1) |
| . . | YM19HU1006P1 | [1] | O-RING,12.42mm ID x 1.78mm Width | KOB(Part of YM19HU1002P1), ID 12.42 ± 0.13 x OD 16mm, Not Shown |
| 8. | YR03H01121P1 | [2] | CONNECTION | KOB(Incls. O-Ring ZD12P01800) |
| 10. | YM19HU1003P1 | [4] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | KOBID 09.25 ± 0.13 x OD 12.81mm Superseded by part number: 9993141 |
| 11. | YM19HU1006P1 | [2] | O-RING,12.42mm ID x 1.78mm Width | KOBID 12.42 ± 0.13 x OD 16mm |
| 13. | 2444Z2516 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2516), ID 10.8mm x OD 13.2mm, Not Shown |
| 14. | YM02HU1122P1 | [1] | ELBOW | KOB45° -- 13/16"-16 x 1/2" PT (male on both ends) |
| 15. | YM19HU1007P1 | [1] | Elbow, 45° -- (Incls. O-Rings ZD12P01400 & YM19HU1003P1) | |
