| . . | YT42H00076F1 | [1] | HYD LINES, CYLINDER | |
| A1. | YT42H01200P1 | [1] | TUBE | KOB |
| A2. | YT42H01201P1 | [1] | TUBE | KOB |
| A3. | YT42H01202P1 | [1] | TUBE | KOB |
| A4. | YR28V00001F1 | [1] | VALVE | KOB |
| A5. | YT42H01290P1 | [2] | BAND | KOB |
| A6. | YT42H01293P1 | [1] | | |
| A7. | YT42H01292P1 | [1] | BAND | KOB |
| A8. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| A9. | YX42H01085P1 | [1] | CONNECTION | KOB1/4"PFx29mm Long (Incls. O-Ring ZD12P01100) |
| A10. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| A11. | 2444Z2338 | [1] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| A12. | 2444T3288 | [1] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| A13. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A14. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A15. | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| A16. | YR43H01003P1 | [1] | CLAMP | KOB |
| A17. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBM08x1.25x50mm |
| A18. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| A19. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| A20. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| A21. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| A22. | YT42H01276P1 | [1] | | |
| A23. | ZA23F12004 | [1] | CONNECTION | KOB |
| A24. | ZA23F12004 | [1] | CONNECTION | KOBELBOW |
| A25. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A26. | YN50S00030F1 | [1] | SWITCH | KOB |
| A27. | ZS18C05040 | [2] | CAPSCREW,Hex, M5 x 40mm | KOBSCREW M05x0.8x40mm |
| A28. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| . . | YT42H00071F1 | [1] | HYD LINES CYLINDER | |
| B1. | YT42H01195P1 | [1] | TUBE | KOB |
| B2. | YT42H01196P1 | [1] | TUBE | KOB |
| B3. | YT42H01197P1 | [1] | RIGID TUBE | KOB |
| B4. | YT42H01198P1 | [1] | TUBE | KOB |
| B5. | YR42H01173P1 | [1] | FLEXIBLE HOSE | KOB |
| B6. | YR42H01174P1 | [1] | FLEXIBLE HOSE | KOB |
| B7. | YR28V00001F1 | [1] | VALVE | KOBASSY, HOLDING |
| B8. | YR42H01192P1 | [1] | BAND | KOB |
| B9. | YR42H01193P1 | [1] | BAND | KOB |
| B10. | YT42H01199P1 | [1] | BAND | KOB |
| B11. | YR42H01116P1 | [1] | BAND | KOB |
| B12. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| B13. | ZA23B22000 | [1] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| B14. | YX42H01085P1 | [1] | CONNECTION | KOB1/4"PFx29mm Long (Incls. O-Ring ZD12P01100) |
| B15. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| B16. | 2444Z2338 | [1] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| B17. | 2444T3288 | [1] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| B18. | ZC26X22011 | [2] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| B19. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| B20. | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| B21. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B22. | ZS18C08030 | [2] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| B23. | ZS18C08050 | [2] | SCREW,Hex, M8 x 50mm | KOBM08x1.25x50mm |
| B24. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| B25. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| B26. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| B27. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B28. | 2414Z199D100 | [3] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| B29. | PY01P01043D3 | [13] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
