| A1. | 2420R349D080 | [2] | HOSE,6.35mm ID x 800mm L | KOB800mm Long (31-1/2 in) |
| A2. | 2420R349D220 | [2] | HOSE,2200.00 mm | KOB Superseded by part number: HX21E04220DX |
| A3. | 2420R349D270 | [2] | HOSE | KOB2700mm Long (106-19/64 in) |
| A4. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| A5. | HM83C10030G1 | [4] | BOLT | KOBM10x30mm |
| A6. | YX52S00013P1 | [2] | SENSOR | SMPressure (Low Pressure) (Incls. O-Ring ZD12P01100) Superseded by part number: LC52S00019P1 |
| A6-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A7. | YF62H01001P1 | [4] | RUBBER BAND | KOB |
| A8. | YN30V00105F1 | [1] | VALVE | KOBAssembly, Pilot, See Full Model Parts Catalog Superseded by part number: YN30V00105F2 |
| A9. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| A10. | ZH32X04006 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| B1. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| B1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| C1. | YN64H01337P1 | [1] | BLOCK | SMManifold |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
