纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (10-013-00[01]) - HYDRAULIC PUMP - VIBRATIONS New Holland Constructuion

作者：广数供应链运营团队

浏览数：

时间：2025-01-21 19:18:01

工程机械零件图册查询

Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴

Pos.	Part No	Qty	Parts name	Comments
. .	ND090921	[1]	HYDRAULIC PUMP	STA
1.	ND102441	[1]	BOX	STA
2.	ND102340	[1]	BEARING	STA
3.	ND102301	[2]	PIN	STA
4.	ND102474	[1]	PLUG	STA
4A.	ND102311	[1]	O-RING	STA
6.	ND102317	[1]	PLUG	STA
6A.	ND102298	[1]	O-RING	STA
7.	ND102322	[3]	FILTER	STA
8.	ND102556	[1]	CYLINDER BLOCK	STA
9.	ND102523	[9]	PISTON ASSY	STA
10.	ND102546	[1]	RETAINER	STA
11.	ND102319	[2]	GUIDE	STA
12.	ND102357	[4]	SPACER	STA
13.	ND102488	[4]	SCREW	STA
14.	ND102554	[1]	LOCK CYLINDER	STA
15.	ND102388	[1]	LEVER	STA
16.	ND102433	[1]	THRUST PLATE	STA
17.	ND102486	[1]	SCREW	STA
18.	ND102557	[1]	GUIDE	STA
19.	ND102345	[1]	SCREW	STA
20.	ND102521	[1]	SPACER	STA
21.	ND102320	[1]	PIN	STA
22.	ND102485	[1]	CONNECTING LINK	STA
23.	ND102432	[1]	SCREW	STA
24.	ND102489	[1]	SPRING	STA
25.	ND102379	[1]	COVER	STA
26.	ND102402	[1]	COVER	STA
27.	ND102542	[1]	PIVOT	STA
28.	ND102532	[2]	SPRING CUP	STA
29.	ND102349	[2]	WASHER	STA
30.	ND102401	[2]	GUIDE	STA
31.	ND102478	[2]	NUT	STA
32.	ND102558	[1]	O-RING	STA
33.	ND102423	[6]	SCREW	STA
35.	ND102323	[2]	SPRING	STA
36.	ND102452	[1]	GUIDE	STA
37.	ND102451	[1]	GUIDE	STA
. .	ND102343	[1]	PISTON	STA
38.	ND102428	[1]	PISTON	STA
39.	ND102342	[2]	O-RING	STA
40.	ND102410	[2]	SEAL	STA
41.	ND102484	[1]	BLOCK	STA
42.	ND102524	[2]	O-RING	STA
43.	ND102327	[2]	O-RING	STA
44.	ND102378	[1]	SLEEVE	STA
45.	ND102424	[3]	SCREW	STA
48.	ND102406	[1]	COVER	STA
49.	ND102338	[1]	BUSHING	STA
50.	ND102483	[1]	BUSHING	STA
51.	ND102464	[1]	GASKET	STA
52.	ND102307	[1]	PLUG	STA
54.	ND102449	[1]	SCREW	STA
55.	ND102346	[1]	SCREW	STA
56.	ND102335	[1]	SPACER	STA
57.	ND102468	[1]	SHAFT	STA
58.	ND102321	[1]	PLATE	STA
59.	ND102487	[6]	SCREW	STA
60.	ND102405	[1]	REPAIR KIT	STA
61.	ND102506	[1]	O-RING	STA
62.	ND102407	[4]	SCREW	STA
63.	ND102636	[1]	COVER	STA
64.	ND102530	[1]	PRESSURE RELIEF VALVE	STA
65.	ND102386	[1]	SCREW	STA
67.	ND102501	[1]	SPRING	STA
68.	ND102334	[1]	CONE	STA
69.	ND102337	[1]	NUT	STA
70.	ND102347	[1]	BALL BEARING	STA
71.	ND102481	[1]	SNAP RING	STA
72.	ND102331	[1]	GASKET	STA
73.	ND102316	[1]	SEAL	STA
74.	ND102568	[1]	O-RING	STA
75.	ND102330	[1]	PLATE	STA
76.	ND102548	[1]	SCREW	STA
77.	ND102332	[1]	SHAFT	STA
78.	ND102508	[2]	HYDRAULIC VALVE	STA
79.	ND102425	[2]	PLUG	STA
80.	ND102637	[1]	PLUG	STA
81.	ND102504	[1]	SPRING	STA
82.	ND102520	[1]	SPRING CUP	STA
83.	ND102528	[1]	PRESSURE RELIEF VALVE	STA
85.	ND102493	[1]	PLUG	STA
85A.	ND102299	[1]	O-RING	STA
86.	ND102344	[1]	GASKET	STA
87.	ND102514	[6]	SCREW	STA
88.	ND102312	[1]	WASHER	STA
89.	ND102480	[1]	SEAL	STA
90.	ND102465	[1]	PLUG	STA
93.	ND102398	[1]	O-RING	STA
94.	ND102476	[1]	SCREW	STA
95.	ND102336	[1]	COVER	STA
96.	ND102447	[1]	CONTROL VALVE	STA
97.	ND102399	[1]	PLATE	STA
98.	ND102479	[1]	SOLENOID VALVE	STA
99.	ND102308	[4]	O-RING	STA
100.	ND102313	[4]	SCREW	STA
101.	ND102400	[1]	SOLENOID VALVE	STA
. .	ND102329	[1]	SEAL KIT	STA
