Pos.	Part No	Qty	Parts name	Comments
. .	ND090919	[1]	HYDRAULIC PUMP	STA
1.	ND102368	[1]	BOX	STA
2.	ND102503	[1]	BEARING	STA
3.	ND102301	[2]	PIN	STA
4.	ND102474	[1]	PLUG	STA
4A.	ND102311	[1]	O-RING	STA
6.	ND102516	[1]	BLOCK	STA
7.	ND102526	[9]	PISTON	STA
8.	ND102547	[1]	PLATE	STA
9.	ND102325	[2]	GUIDE	STA
10.	ND102324	[4]	SPACER	STA
11.	ND102315	[4]	SCREW	STA
12.	ND102616	[1]	SERVICE KIT	STA
13.	ND102612	[1]	LEVER	STA
14.	ND102475	[1]	THRUST PLATE	STA
15.	ND102497	[1]	SCREW	STA
16.	ND102553	[1]	GUIDE	STA
17.	ND102571	[1]	SCREW	STA
18.	ND102521	[1]	SPACER	STA
19.	ND102494	[1]	PIN	STA
20.	ND102517	[1]	CONNECTING LINK	STA
21.	ND102642	[1]	PIN	STA
22.	ND102490	[1]	SPRING	STA
23.	ND102380	[1]	COVER	STA
24.	ND102395	[1]	COVER	STA
25.	ND102617	[1]	LINK	STA
26.	ND102350	[2]	WASHER	STA
27.	ND102601	[2]	GUIDE	STA
28.	ND102398	[2]	O-RING	STA
29.	ND102507	[1]	O-RING	STA
30.	ND102366	[6]	SCREW	STA
31.	ND102493	[1]	PLUG	STA
31A.	ND102299	[1]	O-RING	STA
32.	ND102326	[2]	SPRING	STA
33.	ND102352	[2]	SPRING	STA
34.	ND102477	[1]	PISTON	STA
35.	ND102502	[2]	O-RING	STA
36.	ND102411	[2]	SEAL	STA
37.	ND102369	[1]	BLOCK	STA
38.	ND102353	[2]	O-RING	STA
39.	ND102505	[2]	O-RING	STA
40.	ND102385	[1]	COVER	STA
42.	ND102615	[1]	GASKET	STA
43.	ND102307	[1]	PLUG	STA
48.	ND102550	[1]	SCREW	STA
49.	ND102363	[1]	SCREW	STA
50.	ND102549	[1]	SCREW	STA
51.	ND102426	[1]	SPACER	STA
52.	ND102427	[1]	SPACER	STA
53.	ND102321	[1]	PLATE	STA
54.	ND102487	[6]	SCREW	STA
55.	ND102522	[1]	COUPLING	STA
56.	ND102506	[1]	O-RING	STA
57.	ND102309	[1]	O-RING	STA
58.	ND102495	[1]	ADAPTER	STA
59.	ND102496	[4]	WASHER	STA
60.	ND102333	[4]	SCREW	STA
61.	ND102538	[1]	O-RING	STA
62.	ND102511	[1]	COVER	STA
63.	ND102482	[2]	SCREW	STA
64.	ND102386	[1]	SCREW	STA
65.	ND102298	[1]	O-RING	STA
66.	ND102501	[1]	SPRING	STA
67.	ND102334	[1]	CONE	STA
68.	ND102337	[1]	NUT	STA
69.	ND102509	[1]	BALL BEARING	STA Superseded by part number: 5138660
70.	ND102491	[1]	SNAP RING	STA
71.	ND102567	[1]	RING	STA
72.	ND102492	[1]	SEAL	STA
73.	ND102510	[1]	O-RING	STA
74.	ND102566	[1]	PLATE	STA
75.	ND102305	[3]	SCREW	STA
76.	ND102466	[1]	CONTROL	STA
77.	ND102572	[1]	GASKET	STA
78.	ND102603	[1]	CONNECTING LINK	STA
79.	ND102513	[6]	SCREW	STA
80.	ND102525	[1]	REDUCER	STA
80A.	ND102300	[1]	O-RING	STA
82.	ND102508	[2]	HYDRAULIC VALVE	STA
83.	ND102425	[2]	PLUG	STA
84.	ND102637	[1]	PLUG	STA
85.	ND102504	[1]	SPRING	STA
86.	ND102520	[1]	SPRING CUP	STA
87.	ND102454	[1]	GUIDE	STA
88.	ND102453	[1]	GUIDE	STA
89.	ND102381	[1]	SLEEVE	STA
90.	ND102360	[3]	SCREW	STA
93.	ND102469	[1]	COVER	STA
94.	ND102530	[1]	PRESSURE RELIEF VALVE	STA
95.	ND102515	[1]	SHAFT	STA
96.	ND102318	[2]	O-RING	STA
97.	ND102304	[1]	O-RING	STA
98.	ND102570	[1]	O-RING	STA
99.	ND102518	[1]	HYD CONNECTOR	STA
100.	ND102528	[2]	PRESSURE RELIEF VALVE	STA
101.	ND102322	[3]	FILTER	STA
. .	ND102328	[1]	SEAL KIT	STA
. .	ND102519	[1]	KIT	STA
. .	ND102614	[1]	CONTROL	STA
