| 1. |
84536100
|
[1] |
STOP
|
SAS
|
| 2. |
84384039
|
[1] |
CLEVIS
|
SAS
|
| 2. |
84527316
|
[1] |
CLEVIS
|
SAS
Incl 19
|
| 3. |
6636
|
[4] |
BUSHING
|
CAS
Superseded by part number: 87420247
|
| 4. |
22093
|
[2] |
BUSHING,1-1/2" ID x 1-3/4" OD x 1" Thk
|
FLX
|
| 5. |
84527314
|
[1] |
LINK
|
SAS
Incl 4
|
| 6. |
84384076
|
[4] |
PIN,25.4mm OD x 180mm L
|
SAS
|
| 7. |
50032
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 8
|
WIN
|
| 8. |
9636698
|
[4] |
NUT,1/2"-13, GB
|
NH
Superseded by part number: 88871
|
| 9. |
86632585
|
[1] |
WASHER,1.53" ID x 2.25" OD x 0.06" Thk
|
FOR
|
| 10. |
86624086
|
[2] |
PIN,5/8" x 3", Coiled
|
FOR
|
| 11. |
84384034
|
[1] |
BAR
|
SAS
T-Bar
|
| 12. |
84384019
|
[1] |
LINK
|
SAS
|
| 12. |
84527313
|
[1] |
LINK
|
SAS
Incl 19
|
| 13. |
87500592
|
[2] |
BUSHING,25.5mm ID x 31.84mm OD x 19.05mm L
|
SAS
|
| 14. |
84527311
|
[1] |
LINK
|
SAS
Incl 13
|
| 15. |
84384075
|
[1] |
PIN,31.75mm OD x 342mm L
|
SAS
|
| 16. |
87301770
|
[1] |
BOLT,Hex, 9/16" - 12 x 3-1/4", Gr 8
|
SAS
9/16-12 X 3-1/4 GR8 ZND
|
| 17. |
6035
|
[1] |
LOCK NUT,Hex, 9/16" - 12, Gr 8
|
SAS
.563" UNC GR B YZD Superseded by part number: 280328
|
| 18. |
84527312
|
[1] |
LINK
|
SAS
Incl 3, 13 Superseded by part number: 47622462
|
| 19. |
6635
|
[11] |
BUSHING,25.5mm ID x 31.84mm OD x 25.4mm L
|
FLX
Superseded by part number: 87420246
|
| 20. |
88146
|
[2] |
BOLT,Hex, 1/4" - 20 x 1", Gr 5
|
PA
Superseded by part number: 86505867
|
| 21. |
87361
|
[2] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
| 22. |
CA-250
|
[1] |
PAD
|
FLX
|
| 23. |
84527310
|
[1] |
ARM
|
SAS
Incl 3, 19 - 22
|
