| 1. |
19670
|
[9] |
NUT,5/8"-11, GB
|
NH
Superseded by part number: 85700693
|
| 2. |
87630
|
[4] |
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5
|
NH
Superseded by part number: 280233
|
| 3. |
6035
|
[1] |
LOCK NUT,Hex, 9/16" - 12, Gr 8
|
SAS
Superseded by part number: 280328
|
| 4. |
84557601
|
[1] |
PIN,31.75mm OD x 442mm L
|
SAS
|
| 5. |
87301770
|
[1] |
BOLT,Hex, 9/16" - 12 x 3-1/4", Gr 8
|
SAS
|
| 6. |
88062
|
[1] |
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 8
|
WIN
|
| 7. |
84383983
|
[1] |
MOUNT
|
SAS
|
| 8. |
230-41116
|
[1] |
NUT,1"-8, GA
|
CAS
Superseded by part number: 280286
|
| 9. |
87613202
|
[1] |
WASHER,1.03" ID x 2" OD x 0.06" Thk
|
BRR
|
| 10. |
87315232
|
[1] |
BOLT
|
CAS
|
| 11. |
84534942
|
[1] |
WASHER,25.8mm ID x 51mm OD x 14mm Thk
|
SAS
|
| 12. |
87418581
|
[1] |
PIN,25.4mm OD x 104mm L
|
SAS
|
| 13. |
86624169
|
[2] |
WASHER,1.03" ID x 1.5" OD x 0.06" Thk
|
FOR
|
| 14. |
6392
|
[1] |
SNAP RING,#98, Ext
|
SAS
Superseded by part number: 87019495
|
| 15. |
84573233
|
[1] |
BUSHING
|
SAS
Includes Ref 16
|
| 16. |
6635
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 25.4mm L
|
FLX
Included In Ref 15 Superseded by part number: 87420246
|
| 17. |
84573225
|
[1] |
LINK
|
SAS
|
| 18. |
9627896
|
[4] |
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5
|
NH
|
| 19. |
87686636
|
[2] |
BUSHING,1-1/2" ID x 1-3/4" OD x 1-1/2" Thk
|
SAS
|
| 20. |
84576080
|
[1] |
LINK
|
SAS
|
| 21. |
84418232
|
[1] |
PIN
|
SAS
|
| 22. |
80718
|
[2] |
LUBE NIPPLE,1/4"-28 x 90 Degree
|
GI
Superseded by part number: 87415
|
| 23. |
84418253
|
[1] |
ARM
|
SAS
|
| 24. |
22346
|
[2] |
LOCK PIN,3/8" x 2", Slotted
|
FLX
Superseded by part number: 86624061
|
| 25. |
84490489
|
[1] |
SUPPORT
|
SAS
|
| 26. |
9720
|
[1] |
WEAR STRIP
|
FLX
Superseded by part number: GL-656A
|
| 27. |
8670
|
[4] |
RIVET,Pop, 3/16" OD x 3/4" L
|
FLX
|
