| 1. |
1348
|
[14] |
BOLT,Hex, 3/8"-16 x 1 1/4", G5, Full Thd
|
FLX
Superseded by part number: 88011
|
| 2. |
1378
|
[1] |
BOLT,Hex, 3/8" - 16 x 3", Gr 5
|
FLX
Superseded by part number: 280161
|
| 3. |
1421
|
[1] |
BOLT,Hex, 3/4"-10 x 1 1/2", G5
|
FLX
Superseded by part number: 88692
|
| 4. |
1488
|
[2] |
BOLT,Hex, 3/8"-16 x 1 1/2", G5
|
FLX
Superseded by part number: 88044, 88044, NLS
|
| 5. |
88206
|
[16] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 6. |
87670
|
[10] |
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
|
NH
|
| 7. |
1539
|
[14] |
NUT,1/2"-13, G5
|
FLX
Superseded by part number: 425-108, 425-108, NLS
|
| 8. |
1548
|
[8] |
LOCK NUT,5/16"-18, GC
|
FLX
Superseded by part number: 280736
|
| 9. |
1549
|
[25] |
LOCK NUT,3/8"-16, GB
|
FLX
Superseded by part number: 88902
|
| 10. |
80679
|
[14] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 11. |
1563
|
[41] |
WASHER,3/8"
|
FLX
Superseded by part number: 80702, 80702, NLS
|
| 12. |
1859
|
[2] |
U-BOLT
|
FLX
us 1/2"-13 4 1/8" w 5 1/4" d G5 1 1/4" thread Superseded by part number: 412749A1
|
| 13. |
2115
|
[8] |
LOCK WASHER
|
FLX
3/8" Superseded by part number: 80680
|
| 14. |
2335
|
[8] |
NUT,3/8"-16, G5
|
FLX
Superseded by part number: 280136
|
| 15. |
2427-1
|
[3] |
SPRING
|
IH
3/4"-10, GB
|
| 16. |
3419
|
[2] |
CAP
|
FLX
vinyl 1 5/8" x 1 1/2"
|
| 17. |
6298
|
[2] |
BOLT,Hex, 3/4"-10 x 1 1/4", G5
|
FLX
Hex, 3/4"-10 x 1 1/4", G5 Superseded by part number: 88691
|
| 18. |
6652
|
[4] |
U-BOLT
|
FLX
ur 5/16"-18 x 1 3/4" w 2 3/4" d 1" thread
|
| 19. |
GI-801
|
[1] |
BRACKET
|
FLX
mount, railing
|
| 19. |
84344056
|
[1] |
GRAB RAIL
|
SAS
2011 Bracket, Mountin, Railing, With Toekick
|
| 20. |
GI-830
|
[2] |
HANDRAIL
|
FLX
access
|
| 21. |
GI-864
|
[2] |
MOUNTING PLATE
|
FLX
front access
|
| 22. |
GI-865
|
[1] |
ARM
|
FLX
main support front access
|
| 23. |
GI-866
|
[2] |
BRACKET
|
FLX
front access adjustment
|
| 24. |
GI-867
|
[1] |
BRACKET
|
FLX
front access mount
|
| 25. |
GI-880
|
[2] |
CAP
|
FLX
end, landing extension
|
| 25. |
84360670
|
[2] |
BRACKET
|
SAS
2011 Cap, End, Landing Extension With Toekick
|
| 26. |
GI-881
|
[2] |
CAP
|
FLX
end, landing
|
| 26. |
843690660
|
[2] |
2011 Cap, End, Landing With Toekick
|
|
| 27. |
GI-882
|
[1] |
PLATFORM
|
FLX
front access - long
|
| 27. |
84360668
|
[1] |
PLATFORM
|
SAS
2011 Platform, Front Access, - Long With Toekick
|
| 28. |
GI-883
|
[1] |
PLATFORM
|
FLX
front access - short
|
| 28. |
84360665
|
[1] |
PLATFORM
|
SAS
2011 Platform. Front Access, - Short With Toekick
|
| 29. |
GI-884
|
[1] |
RAIL ASSY.
|
FLX
outer - front access
|
| 29. |
84360642
|
[1] |
GRAB RAIL
|
SAS
2011 Rail Assy, Outer - Front Access With Toekick
|
| 30. |
GI-887
|
[1] |
SUPPORT
|
FLX
post, front landing
|
| 30. |
84360624
|
[1] |
SUPPORT
|
SAS
2011 Support, Post, Front Landing With Toekick
|
| 31. |
84361057
|
[1] |
BRACKET
|
SAS
2011 Bracket Toekick Front Access
|
| 32. |
84361067
|
[1] |
BRACKET
|
SAS
2011 Bracket Toekick Front Access
|
