| 1. |
1976300C1
|
[1] |
BRACKET
|
CAS
FRAME - main
|
| 2. |
1976303C1
|
[1] |
LINK
|
CAS
- top
|
| 3. |
1958440C1
|
[4] |
PIN
|
IH
- quick release
|
| 4. |
1958442C1
|
[4] |
SPRING
|
IH
- release pin tension
|
| 5. |
373523R1
|
[4] |
SNAP RING,#62, .480" Dia, E-Type
|
IH
Ring, Retaining, #62, .480" Dia, E-Type Superseded by part number: 505291
|
| 6. |
480523R1
|
[2] |
HAIR PIN COTTER
|
IH
9/64" dia Superseded by part number: 87327559
|
| 7. |
1976305C1
|
[1] |
BRACKET
|
CAS
- bumper
|
| 8. |
1958352C1
|
[4] |
PAD
|
CAS
- bracket
|
| 12. |
1958381C1
|
[2] |
BAR
|
CAS
BRACKET - drive shaft support
|
| 13. |
413-820
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
- hex, 1/2 NC x 1-1/4 inch Superseded by part number: 72187215, 87670
|
| 14. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 15. |
9413967
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 86992215
|
| 16. |
1958385C1
|
[1] |
ROD
|
CAS
SHAFT - drive
|
| 17. |
138-96
|
[1] |
LOCK PIN,3/16" x 1", Slotted
|
CAS
PIN, 3/16" x 1", Slotted Superseded by part number: 118827
|
| 20. |
433740
|
[1] |
WASHER - shaft backup
|
|
| 21. |
1960268C1
|
[4] |
SPRING
|
CAS
- breakover tension
|
| 22. |
1976306C1
|
[2] |
LINK
|
CAS
- side mounting
|
| 23. |
1976302C1
|
[1] |
TUBE
|
CAS
- stop
|
| 27. |
1976288C1
|
[2] |
ANCHOR
|
CAS
- spring
|
| 28. |
413-880
|
[1] |
BOLT,Hex, 1/2" - 13 x 5", Gr 5
|
CAS
- hex, 1/2 NC x 5 inch Superseded by part number: 87997
|
| 29. |
1976301C1
|
[1] |
STRAP
|
CAS
- cylinder mounting
|
| 30. |
1976304C1
|
[1] |
SPACER
|
IH
- mounting strap Superseded by part number: 1973217C1
|
| 31. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 32. |
3057346R11
|
[2] |
LINCH PIN
|
IH
PIN - clinch Superseded by part number: 1328218C1
|
| 36. |
102545A1
|
[1] |
BRACKET
|
CAS
- guard mounting
|
| 37. |
495-21044
|
[4] |
WASHER,3/8"
|
CAS
(flat, 7/16 x 1 x 5/64 inch) 3/8" Superseded by part number: 87779090, 80702
|
| 38. |
938017R1
|
[7] |
FLANGE NUT,Flg, USR, 5/16"-18
|
IH
- hex flange lock, 5/16 inch NC Superseded by part number: 145458
|
| 39. |
446363
|
[7] |
WASHER,5/16"
|
IH
- flat, 3/8 x 7/8 x 1/16 inch Superseded by part number: 80664
|
| 41. |
1958375C1
|
[1] |
COVER
|
CAS
- PTO
|
| 42. |
1958374C1
|
[1] |
SHIELD
|
CAS
GUARD - drive shaft rear
|
| 43. |
1958372C1
|
[1] |
SHIELD
|
CAS
GUARD - drive shaft front
|
| 44. |
1958373C1
|
[1] |
SUPPORT
|
CAS
BRACKET - guard mounting
|
| 45. |
1960264C1
|
[1] |
PIN
|
CAS
- locking
|
| 46. |
407207R1
|
[1] |
CLIP
|
IH
PIN - cotter, hair, 3/32 inch (Package of 50)
|
| 47. |
434-512
|
[7] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
BOLT - round head square neck, 5/16 NC x 3/4 inch Superseded by part number: 280497, 87779118
|
