| 1. |
1958399C1
|
[1] |
AUGER
|
CAS
- snow thrower
|
| 2. |
1958383C1
|
[2] |
BALL BEARING,1" ID x 2" OD x 1.0629"
|
CAS
BEARING - ball
|
| 3. |
1954930C1
|
[2] |
WASHER
|
IH
- auger shaft
|
| 4. |
462360R1
|
[1] |
FLANGED BEARING
|
IH
- auger Superseded by part number: 86603075
|
| 5. |
413-512
|
[15] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
- hex, 5/16 NC x 3/4 inch Superseded by part number: 72187196, 87872
|
| 6. |
492-11031
|
[15] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 7. |
1958341C1
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - auger
|
| 8. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
CHAIN - auger drive
|
| 9. |
1958343C1
|
[1] |
GUARD
|
CAS
- chain
|
| 10. |
19-205
|
[2] |
SCREW,Hex, 1/4" x 1"
|
CAS
BOLT - hex, self-tapping, 1/4 NC x 1 inch Superseded by part number: 276-20716
|
| 15. |
1958342C1
|
[1] |
PLATE
|
CAS
- auger mounting
|
| 16. |
1976234C1
|
[1] |
DISC
|
CAS
PLATE - auger shaft
|
| 17. |
1958340C1
|
[1] |
SHAFT
|
CAS
- auger
|
| 18. |
413-824
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 19. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
