Pos.	Part No	Qty	Parts name	Comments
1.	208476C1	[3]	ROLL	IH ASSY, lower conveyor idler, roll POS. No. 12, No. 14 and No. 15
2.	210480C92	[1]	CONVEYOR BELT,1524.00 mm W x 3095.00 mm L	IH BELT CONVEYOR , Lower 1524.00 mm W x 3095.00 mm L
. .	218322	[2]	WASHER,0.12" ID x 0.31" OD x 0.03" Thk	IH .125 x .312 x .025 Superseded by part number: 495-31012
3.	210302C1	[2]	SPACER	IH rear roller
4.	389440R91	[2]	BEARING ASSY,31.75mm ID x 72mm OD x 17mm W	IH ASSY
5.	208490C1	[2]	HOUSING	IH ASSY, rear conveyor brg Superseded by part number: 208490C2
6.	455104R11	[7]	COLLAR	IH W/SET SCREW Superseded by part number: 47508357
7.	15282BA	[2]	SPRING	IH rear conveyor
. .	425-1410	[4]	JAM NUT,Jam, 5/8"-11, G5	CAS 5/8-11 znd hex. jam Superseded by part number: 86632556
8.	210477C1	[2]	TUBE	IH bearing housing screw Superseded by part number: 219162C1
. .	20704R1	[2]	WASHER	IH 1-1/32 x 1-1/2 x .105 ga znd Superseded by part number: 86624170
. .	21211R1	[2]	WASHER	IH 25/32 x 1-1/2 x 7 ga znd Superseded by part number: 495-81255
9.	208372C1	[2]	BRACKET	IH spring anchor
. .	18494R1	[4]	BOLT,Hex, 3/8" - 16 x 1", Gr 2	IH 3/8 x 1 znd hex-hd mach Superseded by part number: 424-616
10.	617863R1	[8]	FLANGED BEARING	IH brg mounting
. .	17351R1	[12]	CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2	IH BOLT, 3/8 x 1 znd sq-nk crg Superseded by part number: 88682
. .	482256R1	[12]	BEARING LOCK NUT,Flg, USR, 3/8"-16	IH 3/8-16 znd hex lock Superseded by part number: 247780
11.	485259R91	[4]	BEARING ASSY,1.2505" ID x 72 mm OD x 1.4844"	IH ASSY, lower conveyor idler roll Superseded by part number: 47577205
12.	208481C1	[1]	PIPE	IH roll POS. No. 13
13.	208483C1	[1]	SHAFT	IH idler roller
. .	18780R1	[2]	BOLT,Hex, 3/8"-16 x 1 3/4", G2	IH 3/8 x 1-3/4 znd hex-hd mach Superseded by part number: 424-628
14.	208482C91	[2]	BEARING ASSY	IH roller idler Superseded by part number: 87446552
15.	208494C1	[2]	ANCHOR	IH ASSY, roller
16.	210364C1	[2]		P SHIM, spacer, (or as req.)
17.	210481C2	[1]	PIN	IH belt connector Superseded by part number: 214299C1
17.	210321C1	[1]	TOOL	IH LACER, belt, not illustrated
17.	208790C1	[1]	PACKAGE	IH KIT, No. 4 clipper belt hook, see operator's manual
18.	213561C1	[1]	ROLL	IH ASSY, tapered idler, roll POS. No. 17 Superseded by part number: 214396C1, 214275C1, 214274C1, 213864C1
19.	612031R1	[4]	FLANGED BEARING	IH roller brg Superseded by part number: 50591
. .	18697R1	[4]	CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 1 3/4", Gr 2	IH BOLT, 5/16 x 3/4 znd sq-nk crg Superseded by part number: 86508778
. .	938017R1	[4]	FLANGE NUT,Flg, USR, 5/16"-18	IH 5/16-18 znd hex. lock Superseded by part number: 145458
20.	204807C91	[2]	BEARING ASSY,25.4mm ID x 52mm OD x 15mm W	CAS roller
21.	455102R21	[2]	COLLAR	IH W/SET SCREW, brg locking Superseded by part number: 47577183
22.	208484C1	[2]	ROLLER	IH ASSY, front, roll POS. No. 16
24.	462360R1	[8]	FLANGED BEARING	IH brg mounting Superseded by part number: 86603075
. .	16897R1	[12]	CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd	IH BOLT, 5/16 x 3/4 znd sq-nk crg Superseded by part number: 412-512
26.	208465C2	[1]	ROLL	IH ASSY, lower conveyor, roll POS. No. 11
27.	173735C91	[1]	BEARING ASSY	IH lower conveyor end RH Superseded by part number: F86214
29.	208475C91	[1]	BEARING ASSY	IH BEARING W/HOUSING, lower conveyor end RH
. .	550796R1	[3]	CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5	IH BOLT, 3/8 x 1-1/4 znd sq-nk crg Superseded by part number: 86508749
. .	9411655	[3]	LOCK NUT,3/8"-16, GB	IH NUT, 3/8-16 cad hex. lock Superseded by part number: 88902
30.	208474C1	[1]	PLATE	IH lower conveyor spacer LH
. .	466971R1	[4]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5	IH BOLT, 1/2 x 2 znd sq-nk crg Superseded by part number: 280185
. .	487374R1	[4]	BEARING LOCK NUT,Flg, USR, 1/2"-13	IH 1/2 znd hex. lock Superseded by part number: 86512371
32.	172408C91	[1]	BALL BEARING,49.21mm ID x 90mm OD x 23mm W	IH BEARING ASSY, lower conveyor end LH Superseded by part number: 685727
33.	618032R11	[1]	COLLAR	IH W/SET SCREW, brg locking
34.	208473C91	[1]	BEARING ASSY	IH BEARING W/HOUSING, lower conveyor LH
