| 1. |
213556C1
|
[2] |
CHANNEL
|
IH
rear tube assy
|
| . . |
18674R1
|
[4] |
BOLT,Short NK, 5/16"-18 x 1 1/2", G2
|
IH
5/16 x 1-1/2 znd sq-nk crg Superseded by part number: 598805R1
|
| . . |
938017R1
|
[8] |
FLANGE NUT,Flg, USR, 5/16"-18
|
IH
5/16-18 znd hex lock Superseded by part number: 145458
|
| . . |
127507H
|
[4] |
WASHER
|
IH
.406 x .875 x .164 pln Superseded by part number: 21309R1
|
| 2. |
213553C1
|
[1] |
TUBE
|
IH
ASSY, rear upper to cyl RH
|
| 3. |
213551C1
|
[1] |
TUBE
|
IH
ASSY, rear lower to cylinder RH 90 deg swivel
|
| 4. |
607005R91
|
[4] |
HOSE
|
IH
cyl upper and lower
|
| 5. |
671796R1
|
[4] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
IH
7/8-14 to 9/16-18 37 deg hyd flared tube adj str thd 90 deg reducer w/o-ring Superseded by part number: 86512937
|
| 6. |
364885R1
|
[7] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
IH
.625 OD tube Superseded by part number: 167269
|
| 7. |
673582R11
|
[2] |
TUBE,0.375" OD, 17, 1.2" Length
|
IH
ASSY, cyl upper
|
| 8. |
392743R92
|
[2] |
CYLINDER
|
IH
ASSY, hydraulic, refer to cyl, 1 for components
|
| . . |
386685R91
|
[1] |
KIT
|
IH
KIT, o-ring & seal
|
| . . |
27577R1
|
[2] |
PIN
|
CAS
5/8 x 3-5/16 znd std-hd Superseded by part number: S10832
|
| . . |
18481R1
|
[2] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| . . |
25419R1
|
[2] |
PIN
|
IH
1 x 2-3/4 znd std-hd Superseded by part number: 86632567
|
| . . |
20340R1
|
[2] |
COTTER PIN,1/4" x 1 1/2"
|
IH
Pin, Split (Cotter), 1/4" x 1 1/2" Superseded by part number: 80753
|
| 9. |
9402786
|
[6] |
UNION,9/16"-18, 37 Degree x 9/16"-18, 37 Degree
|
IH
9/16-18 37 deg hyd flared tube Superseded by part number: 128821
|
| 10. |
279026R91
|
[2] |
HOSE CLAMP,#36, 1.81/2.75 Type F Worm
|
IH
CLAMP, hose Superseded by part number: 86624194
|
| 11. |
532875R1
|
[2] |
FITTING
|
IH
RESTRICTOR, hyd line
|
| 12. |
9410282
|
[2] |
ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw
|
IH
7/8-14 37 deg hyd flared tube 90 deg swivel Superseded by part number: 182977
|
| 13. |
9403402
|
[2] |
REDUCER,37 Degree, 5/8" x 1/4" Tube
|
IH
9/16-18 37 deg hyd flared tube Superseded by part number: 86513080
|
| 14. |
9403529
|
[2] |
TUBE NUT,37 Degree, 7/8"-14, Type B
|
IH
NUT, 7/8-14 37 deg flared tube Superseded by part number: 9626918
|
| 15. |
213552C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, rear upper to cylinder LH
|
| 16. |
213550C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, rear lower to cylinder LH
|
| 17. |
213600C1
|
[2] |
ANGLE
|
IH
hydraulic lines
|
| 18. |
299404C1
|
[12] |
CLAMP
|
IH
3/8 PHC closed coated Superseded by part number: 86572009
|
| 19. |
213548C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, frt lower to rear upper LH
|
| 20. |
213546C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, front upper to rear lower LH
|
| 21. |
213554C1
|
[1] |
TUBE,9.525 mm OD, 88.9 mm Length
|
IH
ASSY, check valve to line
|
| 22. |
27291R1
|
[2] |
CLAMP
|
IH
1 PHC closed coated Superseded by part number: 9827902
|
| . . |
18764R1
|
[2] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 type 1 Superseded by part number: 424-512
|
| 23. |
9410202
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
IH
CONNECTOR, 9/16-18 37 deg hyd flared tube short swivel Superseded by part number: 76350
|
| 24. |
364839R1
|
[4] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
IH
6-1, 90 Duro, .468" ID x .078" Thk, 3/8 OD tube Superseded by part number: 9617873
|
| 25. |
673293R92
|
[1] |
VALVE
|
IH
ASSY, double action check, see check valve assy
|
| . . |
18782R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 2
|
IH
3/8 x 2-1/4 type 1 Superseded by part number: 88546
|
| . . |
124829
|
[2] |
JAM NUT,Hex, 3/8" - 16, Gr 5
|
IH
Superseded by part number: 329-146
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 26. |
26210R1
|
[2] |
HYD CONNECTOR,7/8"-14, 37 Degree x 9/16"-18, O-Ring
|
IH
CONNECTOR, 9/16-18 37 deg hyd flared tube short reducer Superseded by part number: 218-5360
|
| 27. |
151021H1
|
[2] |
HOSE
|
IH
ASSY, tractor to check valve hyd, replaces 218465C2
|
| 28. |
213555C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, relief valve to check valve
|
| 29. |
9410976
|
[1] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
IH
9/16-18 37 deg flared tube adj str thd 90 deg Superseded by part number: 76344
|
| 30. |
538731R1
|
[1] |
BOLT,U, 5/16" - 18 x 2.30"
|
IH
U-BOLT, relief valve assy.
|
| 31. |
9410332
|
[2] |
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
|
IH
9/16-18 37 deg hyd flared tube swivel, 90 deg Superseded by part number: 129274
|
| 32. |
9403371
|
[1] |
CAP,37 Degree, 9/16"-18
|
IH
9/16-18 37 deg hyd flared tube Superseded by part number: 574342
|
| 33. |
208621C91
|
[1] |
VALVE
|
IH
ASSY, relief, see relief valve assembly
|
| 34. |
9410306
|
[2] |
TEE,37 Degree, 9/16"-1 x 9/16"-18, Fem Sw Br
|
IH
9/16-18 37 deg hyd flared tube swivel Superseded by part number: 86513014
|
| 35. |
213570C1
|
[1] |
PLUG
|
IH
orifice
|
| 36. |
213569C1
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR, reducer
|
| 37. |
213549C1
|
[1] |
TUBE
|
IH
ASSY, frt lower to rear upper RH
|
| 38. |
213547C1
|
[1] |
HYD TUBE
|
IH
TUBE ASSY, frt upper to rear lower RH
|
| . . |
395149R1
|
[1] |
QUICK MALE COUPLING
|
IH
COUPLER, poppet type, 7/8-14 thread, hydraulic Superseded by part number: 86615558
|
| . . |
544787R91
|
[1] |
COUPLING, BREAK AWAY
|
IH
COUPLER, self sealing type, 7/8-14 thread, hydraulic Superseded by part number: 1341843C1
|
| . . |
1272399C2
|
[1] |
QUICK MALE COUPLING
|
IH
COUPLER, self sealing type, ISO standard, 7/8-14 thread, hydraulic Superseded by part number: 86615558
|
| . . |
1285718C2
|
[1] |
QUICK MALE COUPLING
|
IH
COUPLER, self sealing type, ISO standard, 3/4-16 thread, hydraulic
|
| . . |
570828R1
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
IH
1/2 OD tube class 6, use on couplers with 3/4-16 threads, hydraulic Superseded by part number: 128825
|
| . . |
407045R1
|
[1] |
FITTING
|
IH
BUSHING, 3/4-16 str thd x 7/8-14 str thd, used on adapt 3/4-16 hose fitting to 7/8-14 coupling, hydraulic Superseded by part number: 84323487
|
| . . |
407545R1
|
[1] |
FITTING
|
IH
BUSHING REDUCER, 7/8-14 str thd x 3/4-16 str thd, used to adapt 7/8-14 hose fitting to 3/4-16 coupling, hydraulic Superseded by part number: 1252129C1
|
| . . |
935433R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 7/8"-14, O-Ring
|
IH
CONNECTOR, C-Z hyd fld 5/8 to 3/8 sht, used on 7/8-14 str thd couplers, hydraulic Superseded by part number: 525646
|
| . . |
607728R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 1/2"-14, NPTF
|
IH
CONNECTOR, C-Z hyd fld 1/2 to 3/8, used on 1/2 in. pipe couplers, hydraulic Superseded by part number: 19956
|
| . . |
587639R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 3/4"-18, O-Ring
|
IH
CONNECTOR, C-Z hyd fld 1/2 to 3/8 sht, used on 3/4 in. pipe couplers, hydraulic Superseded by part number: 128817
|
