| 1. |
208456C1
|
[2] |
DRIVE SPROCKET
|
IH
SPROCKET, upper belt drive
|
| . . |
426374
|
[2] |
SET SCREW,Hex Soc, 3/8"-16 x 1/2"
|
IH
SCREW, 3/8-16 x 1/2 znd hdls hex-soc set Superseded by part number: 87023136
|
| . . |
103411
|
[2] |
|
NNA
SPLIT (COTTER), 3/16" x 2" Superseded by part number: 432-1232, 432-1232, NLS
|
| . . |
22812R1
|
[20] |
WASHER
|
IH
1-15/32 x 2 x 16 ga znd Superseded by part number: 495-81220
|
| 2. |
Q63
|
[2] |
KEY,3/8" Sq x 1 1/2", Par
|
IH
3/8 x 1-1/2 sq parallel Superseded by part number: 86977757
|
| . . |
574532R91
|
[1] |
CLIP, SPRING
|
IH
LINK, #60 single pitch connecting Superseded by part number: 241-1316
|
| 4. |
208459C2
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, press roll
|
| . . |
22210R1
|
[1] |
SET SCREW,Hex Soc, 5/16"-18 x 1/2"
|
IH
SCREW, 5/16-18 x 1/2 znd hlds hex-soc Superseded by part number: 80442
|
| 5. |
581306R1
|
[1] |
KEY,5/16" Sq x 1 1/4", Par
|
IH
|
| 6. |
208457C2
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, main drive and press roll drive
|
| 7. |
119461R91
|
[1] |
BEARING, ROLLER, CYL,25mm ID x 52mm OD x 20.64mm W
|
IH
ASSY, sprocket, outer
|
| 8. |
208633C1
|
[1] |
OIL SEAL
|
IH
brg oil
|
| 9. |
208462C1
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, pickup drive
|
| 10. |
208461C1
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, drive lower conveyor
|
| . . |
20705R1
|
[3] |
WASHER
|
IH
1.781 x 2.50 x .054 znd (or as required) Superseded by part number: 87613203
|
| . . |
21795R1
|
[2] |
WASHER,1.78" ID x 2.5" OD x 0.03" Thk
|
IH
1.781 x 2.50 x .027 znd (or as req.) Superseded by part number: 495-81005
|
| 11. |
388418C1
|
[1] |
SPECIAL WASHER,19.84mm ID x 81.28mm OD x 6.35mm Thk
|
IH
.781 x 3.2 x 1/4 ht
|
| . . |
27028R1
|
[1] |
SCREW, 3/4-10 x 1-1/4 PHC hex-hd lock
|
|
| . . |
456929R91
|
[1] |
CHAIN LINK
|
IH
LINK, #2050 double pitch offset Superseded by part number: 86595273
|
| . . |
456980R91
|
[1] |
CHAIN LINK
|
IH
LINK, #2050 double pitch connecting
|
| 13. |
582415R91
|
[1] |
DRIVE SPROCKET,9T
|
IH
SPROCKET ASSY, pickup idler
|
| . . |
589068R1
|
[4] |
WASHER
|
IH
.656 x 1.250 x .105 znd Superseded by part number: 495-51066
|
| . . |
18721R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 1/4", Gr 2
|
IH
BOLT, 5/8 x 2-1/4 znd sq-nk crg Superseded by part number: 280508
|
| . . |
9413969
|
[1] |
NUT,5/8"-11, GB
|
IH
5/8 cad hex. lock Superseded by part number: 9413960
|
| . . |
654438R91
|
[2] |
LINK
|
IH
#80 single pitch connecting Superseded by part number: 241-1418
|
| . . |
654440R91
|
[1] |
LINK
|
IH
#80 single pitch roller Superseded by part number: 140774
|
| 17. |
208464C1
|
[1] |
BOLT
|
IH
EYEBOLT, idler adjusting
|
| . . |
120238
|
[2] |
JAM NUT,Jam, 1/2"-13, G5
|
IH
1/2-13 znd hex. jam Superseded by part number: 329-148
|
| . . |
18733R1
|
[1] |
BOLT
|
IH
3/4 x 2-1/2 znd sq-nk crg Superseded by part number: 111-707
|
| . . |
9413971
|
[1] |
LOCK NUT,3/4"-10, GB
|
IH
NUT, 3/4-10 cad hex. lock Superseded by part number: 280375
|
| . . |
22767R1
|
[1] |
WASHER
|
IH
1-3/32 x 1-1/2 x 11 ga znd Superseded by part number: Q216
|
| . . |
21758R1
|
[2] |
WASHER
|
IH
.781 x 1.250 x .067 znd (or as required) Superseded by part number: 495-81038
|
| . . |
21211R1
|
[2] |
WASHER
|
IH
.781 x 1.500 x .164 znd Superseded by part number: 495-81255
|
| 18. |
208455C91
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET ASSY, main drive idler Superseded by part number: 51200277
|
| 19. |
208458C2
|
[1] |
SPACER
|
IH
brg, inner
|
| 20. |
280428C91
|
[1] |
BEARING ASSY,0.9847" ID x 2.0472" OD x 0.5006"
|
IH
ASSY, sprocker, inner Superseded by part number: 467146R91
|
| 21. |
208634C1
|
[1] |
SPACER
|
IH
brg, outer
|
| 22. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self-tap lub
|
