| 1. | ZA105005 | [4] |
BELT |
IH- roller, endless, 11 inch (279 MM) wide (Alternate part is ZA105003) Superseded by part number: 700709544 |
| 2. | ZA105003 | [4] |
BELT |
IH- Roller, 11 inch (279 mm) wide (Alternate part is ZA105005) Superseded by part number: 700724731 |
| 3. | ZA102977 | [1] |
PIN |
IH- belt |
| 4. | ZA105917 | [1] |
ROLLER |
CASASSEMBLY - number 9 |
| 5. | ZA105919 | [1] |
ROLLER |
CASASSEMBLY - number 10 |
| 6. | ZA105982 | [1] |
DIVIDER |
CAS- belt |
| 7. | ZA105910 | [1] |
STRIPPER |
CASSCRAPER - roller |
| 8. | ZA105794 | [2] |
BALL BEARING |
CASBEARING - hex bore, 1.25 inch (32 MM) ID Superseded by part number: 47442495 |
| 9. | ZA105799 | [2] |
COLLAR |
CAS- bearing |
| 13. | ZA104986 | [1] |
BRACKET |
IHTIGHTENER - right |
| 14. | ZA104987 | [1] |
BRACKET |
IHTIGHTENER - left |
| 15. | ZA104982 | [2] |
CLIP |
IH- angle |
| 16. | 120377 | [4] |
NUT,3/8" - 16, Gr 5 |
IH Superseded by part number: 280136 |
| 18. | NSS | [1] |
NOT SOLD SEPARAT |
CONCHAIN ASSEMBLY - roller 10 to roller 4 (Use 151 links from bulk chain 611362R91, and 1 connecting link 574532R91) |
| . . | 611362R91 | [1] |
CHAIN (AG) |
IHCHAIN - 10 foot (3 M) roll Superseded by part number: 611362R91X |
| . . | 574532R91 | [1] |
CLIP, SPRING |
IHLINK - chain, connecting Superseded by part number: 241-1316 |
| 20. | 27908R1 | [2] |
BOLT,1/2" x 1 1/4", Gr 8 |
CAS- hex, 1/2 NC x 1-1/4 inch, grade 8 |
| 21. | 357020R1 | [2] |
WASHER |
IH- flat, 17/32 x 1-3/4 x 1/4 inch (13 x 44 x 6 MM) |
| 22. | ZA104656 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 52 tooth (Standard) Superseded by part number: 136475A1 |
| 22. | ZA104624 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 42 tooth (Power reduction) Superseded by part number: 700120248 |
| 23. | ZA104607 | [1] |
SPACER |
IH- sprocket |
| 24. | ZA104227 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 30 tooth |
| 25. | ZA104619 | [1] |
HUB |
IH- splined |
| 26. | ZA104229 | [1] |
SPROCKET ASSY. |
IHSPROCKET - 30 tooth |
| 27. | 22822R1 | [1] |
WASHER |
IH- flat, 1-21/32 x 2-1/2 x 3/64 inch (42 x 64 x 1 MM) Superseded by part number: L31792 |
| 28. | 663562R1 | [4] |
FLANGE |
IHHOUSING - bearing |
| 29. | 96328C1 | [2] |
BALL BEARING,40mm ID x 80mm OD x 22mm W |
CAS- ball, 1.57 inch (40 MM) ID |
| 30. | ZA104823 | [1] |
PLATE |
IH- right |
| 31. | 219-37 | [2] |
LUBE NIPPLE,45 Degree Elbow, 1/4" - 28 NPTF |
CASFITTING - grease, 45 degree, 1/4 inch PTF Superseded by part number: 87569 |
| 32. | REF | [2] |
INSTRUCTION |
NHDECAL - grease, 50 hours (See page 62) |
| 33. | 1254040C1 | [1] |
LACER - belt, 6 inch (152 MM) | |
| . . | 208790C1 | [1] |
PACKAGE |
IHKIT - repair, belt (Box of lacing hooks) |
