| 1. | ZA104550 | [1] |
TRAILER HITCH |
CASHITCH ASSEMBLY - with decals |
| 2. | REF | [1] |
INSTRUCTION |
NHDECAL - caution, 540 RPM PTO (See page 62) |
| 6. | ZA103986 | [1] |
HOLDER |
IH- hose |
| 7. | 180177 | [1] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5 |
IH- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410 |
| 8. | 120390 | [1] |
WASHER,1/2" |
IH- flat, 9/16 x 1-3/8 x 3/32 inch (14 x 35 x 2 MM) Superseded by part number: 106265 |
| 9. | NLS | [8] |
NO LONGER SERVICED |
BAS- hex, 5/8 NC x 1-1/2 inch |
| 10. | 28425R1 | [24] |
WASHER |
IH- flat, hardened Superseded by part number: 86624156 |
| 11. | 492-11062 | [8] |
BEARING WASHER,5/8" |
CASWASHER, LOCK, 5/8" Superseded by part number: 86729275 |
| 12. | 280374 | [6] |
NUT,Hex, 5/8" - 11, Gr 5 |
NH- hex, 5/8 inch NC |
| 14. | ZA105933 | [1] |
FRAME |
CASASSEMBLY - front, with decals |
| 21. | 413-1032 | [6] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5 |
CAS- hex, 5/8 NC x 2 inch Superseded by part number: 86505999 |
| 22. | 20166R1 | [4] |
BOLT,Hex, 5/8" - 11 x 6", Gr 5 |
IH- hex, 5/8 NC x 6 inch Superseded by part number: 18610R1 |
| 23. | 87414 | [2] |
LUBE NIPPLE,1/4" - 28 |
NHFITTING - grease, thread forming, 1/4 inch |
| 24. | ZA105769 | [1] |
BRACKET |
CASASSEMBLY - actuator |
| 27. | ZA105930 | [1] |
FRAME |
CASASSEMBLY - main, with decal |
| 29. | ZA104626 | [2] |
BRACKET |
IH- retainer |
| 30. | 180122 | [4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5 |
IH- hex, 3/8 NC x 1 inch Superseded by part number: 113-207 |
