| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| F049200 | [1] | HARVESTER UNIT | ||
| 1. | F049140 | [1] | Link | |
| 1. | F602508 | [1] | Link | |
| 2. | F003531 | [4] | Screw | |
| 3. | F005551 | [4] | Lock Washer | |
| 4. | F021304 | [4] | SHAFT ASSY | |
| 5. | F011186 | [8] | Sleeve | |
| 6. | F026294 | [2] | Cylinder | |
| 7. | F031070 | [2] | Washer | |
| 8. | F005626 | [10] | GREASE NIPPLE | |
| 9. | F021319 | [2] | Shaft | |
| 10. | F021366 | [4] | Spacer | |
| 11. | F003373 | [4] | CIRCLIP | |
| 12. | F003820 | [2] | SPHERICAL BEARING | |
| 13. | F018239 | [2] | Spacer | |
| 14. | F019244 | [2] | Lock Nut | |
| 15. | F049165 | [1] | Leg | |
| 15. | F602541 | [1] | Frame | |
| 16. | F021277 | [1] | DELIMBING KNIFE | |
| 17. | F003551 | [4] | Screw | |
| 18. | F005494 | [4] | Lock Nut | |
| 19. | F015779 | [8] | SPLIT PIN | |
| 20. | F050207 | [4] | Hydraulic Cylinder | |
| 21. | F018229 | [8] | Pin | |
| 22. | F019886 | [16] | Spacer | |
| 23. | F046927 | [1] | Bracket | |
| 24. | F602510 | [1] | Bracket | |
| 25. | F019970 | [2] | Shaft | |
| 26. | F018838 | [6] | Lock Nut | |
| 27. | F019969 | [2] | Shaft | |
| 28. | F019968 | [2] | Spacer | |
| 29. | F052433 | [1] | Measuring Wheel | |
| 30. | F021201 | [2] | Shaft | |
| 31. | F049238 | [1] | SAW TRANSMISSION | |
| 31. | F049239 | [1] | AUTOM. CHAIN TIGHTENER | |
| 31. | F049240 | [1] | AUTOM. CHAIN TIGHTENER | |
| 32. | F019192 | [1] | DELIMBING TOOL | |
| 33. | F019191 | [1] | DELIMBING TOOL | |
| 34. | F046322 | [8] | BEARING BUSHING | |
| 35. | F014647 | [1] | Cylinder | |
| 36. | F031071 | [2] | Shaft | |
| 37. | F014675 | [4] | SPACER RING | |
| 38. | F030459 | [1] | Hydraulic Motor | |
| 38. | F022655 | [1] | Hydraulic Motor | |
| 39. | F050462 | [1] | PROTECTION ASSY | |
| 40. | F050456 | [1] | PROTECTION ASSY | |
| 41. | F022962 | [2] | FEED WHEEL | |
| 41. | F013128 | [2] | FEED ROLL | |
| 41. | F031228 | [2] | SPIKED ROLL | |
| 41. | F034481 | [2] | FEED WHEEL | |
| 41. | F041585 | [2] | FEED WHEEL | |
| 42. | F008445 | [6] | Screw | |
| 43. | F025639 | [1] | HEAD | |
| 43. | F038621 | [1] | Pin | |
| 44. | F050569 | [1] | DELIMBING TOOL | |
| 45. | F050570 | [1] | DELIMBING TOOL | |
| 46. | F035537 | [1] | Sign | |
| 46. | F045934 | [1] | Sign | |
| 46. | F050419 | [1] | Sign | |
| 46. | F045957 | [1] | Sign | |
| 46. | F045941 | [1] | Sign | |
| 47. | F003541 | [2] | Screw | |
| 48. | F043523 | [1] | HYDRAULIC VALVE | |
| 48. | F054658 | [1] | HYDRAULIC VALVE | |
| 49. | F003564 | [1] | Nut | |
| 50. | F021485 | [2] | Screw | |
| 51. | F019359 | [2] | DAMPER | |
| 53. | F007787 | [8] | Screw | |
| 54. | F003541 | [4] | Screw | |
| 54. | F005208 | [2] | Cotter Pin | |
| 55. | F040644 | [6] | Screw | |
| 56. | F050563 | [1] | Case | |
| 57. | F050488 | [1] | Case | |
| 58. | F050533 | [1] | Case | |
| 59. | F021332 | [1] | REFILLING COVER | |
| 60. | F021333 | [1] | Cap | |
| 61. | F022656 | [1] | Seal | |
| 62. | F012623 | [1] | Ball | |
| 63. | F012624 | [1] | Spring | |
| 64. | F010721 | [1] | Washer | |
| 65. | F012625 | [1] | CIRCLIP | |
| 66. | F046894 | [1] | SIGNS MOUNTING | |
| 66. | F046895 | [1] | SIGNS MOUNTING | |
| 66. | F046896 | [1] | SIGNS MOUNTING | |
| 66. | F046897 | [1] | SIGNS MOUNTING | |
| 66. | F046899 | [1] | SIGNS MOUNTING | |
| 67. | F049207 | [2] | Sign | |
| 68. | F018602 | [1] | DECAL | |
| 69. | F044080 | [6] | Sign | |
| 70. | F036544 | [2] | DECAL | |
| 70. | F031016 | [2] | DECAL | |
| 70. | F036512 | [2] | DECAL | |
| 70. | F036479 | [2] | DECAL | |
| 70. | F036448 | [2] | DECAL | |
| 71. | F044079 | [1] | Sign | |
| 71. | F045486 | [1] | Sign | |
| 71. | F045493 | [1] | Sign | |
| 71. | F045505 | [1] | Sign | |
| 71. | F045499 | [1] | Sign | |
| 72. | F003536 | [1] | Screw | |
| 73. | F002805 | [2] | Lock Washer | |
| 74. | F029896 | [1] | Bracket | |
| 75. | F029895 | [1] | Bracket |
