| 1. |
|
|
|
24V60A
|
| 2. |
842449
|
[1] |
Instrument panel
|
12V
|
| 2. |
842450
|
[1] |
Instrument panel
|
24V
|
| 3. |
|
|
|
MO-12337/XXXX., 12V repl by 843511
|
| 3. |
842774
|
[1] |
Starter motor
|
Repl by 847307
|
| 3. |
843511
|
[1] |
Starter motor
|
MO 12338/XXXX-., 12V repl by 847306
|
| 3. |
843510
|
[1] |
Starter motor
|
MO 12338/XXXX-., 24V repl by 847307
|
| 3. |
847306
|
[1] |
Starter motor
|
12V
|
| 3. |
847307
|
[1] |
Starter motor
|
24V
|
| 4. |
953486
|
[3] |
Stud
|
|
| 5. |
942336
|
[3] |
Spring washer
|
|
| 6. |
955827
|
[3] |
Hexagon nut
|
|
| 7. |
|
|
|
12V38A,24V25A
|
| 7. |
823766
|
[1] |
Governor
|
24V60A
|
| 8. |
842345
|
[1] |
Bracket
|
|
| 9. |
821540
|
[1] |
Spacer sleeve
|
|
| 10. |
955536
|
[1] |
Hexagon screw
|
L=45mm
|
| 10. |
940114
|
[2] |
Hexagon screw
|
L=22mm
|
| 11. |
942336
|
[3] |
Spring washer
|
|
| 12. |
837791
|
[2] |
Clutch housing
|
Repl by 1 PC 845838, 1 PC 955129
|
| 13. |
955524
|
[3] |
Hexagon screw
|
|
| 14. |
941907
|
[3] |
Spring washer
|
|
| 15. |
837829
|
[1] |
Terminal block
|
|
| 16. |
88578
|
[1] |
Fuse box
|
|
| 17. |
943905
|
[2] |
Fuse
|
25A
|
| 18. |
837796
|
[4] |
Fitting screw
|
|
| 19. |
17602
|
[8] |
Hexagon nut
|
|
| 20. |
941616
|
[4] |
Cross recessed screw
|
|
| 21. |
77796
|
[2] |
Fuse
|
50A
|
| 21. |
239148
|
[2] |
Fuse
|
80A
|
| 23. |
941269
|
[2] |
Plug
|
|
| 24. |
|
|
|
|
| 25. |
950144
|
[2] |
Screw
|
|
| 26. |
120265
|
[2] |
Washer
|
|
| 27. |
955512
|
[1] |
Hexagon screw
|
|
| 28. |
941906
|
[1] |
Spring washer
|
|
| 29. |
842453
|
[1] |
Cable block
|
Engine
|
| 29. |
837836
|
[1] |
Cable block
|
Connector, instrument panel
|
| 29. |
842451
|
[1] |
Cable block
|
Alternator, starter, connecting screw., 12V38A,24V25A
|
| 29. |
842452
|
[1] |
Cable block
|
|
| 30. |
825738
|
[1] |
Cable block
|
L=2500mm
|
| 30. |
820419
|
[1] |
Cable block
|
L=7000mm
|
| 31. |
827150
|
[1] |
Sensor
|
|
| 32. |
822858
|
[1] |
Thermo monitor
|
|
| 33. |
843231
|
[1] |
Oil pressure sensor
|
|
| 34. |
843812
|
[1] |
Contact, switch nipple
|
Stop
|
| 35. |
942490
|
[1] |
T-nipple
|
|
| 36. |
880281
|
[1] |
Pressure monitor, oil pressure sender hour indicator
|
|
| 36. |
|
|
|
|
| 37. |
180002
|
[1] |
Nipple
|
|
| 38. |
354671
|
[1] |
Tachometer sensor
|
See group 2A (837783)
|
| 39. |
925059
|
[1] |
O-ring
|
See group 2A
|
| 40. |
837781
|
[1] |
Oil pressure sensor, pressure sensor reverse gear
|
See group 4A
|
| 40. |
|
|
|
|
| 40. |
837782
|
[1] |
Pressure sensor
|
See group 2B
|
| 41. |
957181
|
[2] |
Gasket
|
|
| 42. |
837993
|
[1] |
Instrument panel
|
-instrument panel for hour indicator and extra alarm device., 12V
|
| 42. |
837994
|
[1] |
Instrument panel
|
-instrument panel for hour indicator and extra alarm device., 24V
|
| 43. |
837995
|
[1] |
Instrument panel
|
Instrument panel for tank gauge and rudder angel indicator, 12V
|
| 43. |
837996
|
[1] |
Instrument panel
|
Instrument panel for tank gauge and rudder angel indicator, 24V
|
| 44. |
837772
|
[1] |
Position sensor
|
|
| 45. |
837999
|
[1] |
Sensor
|
|
| 46. |
956078
|
[4] |
Cross recessed screw
|
L=16mm
|
| 46. |
956081
|
[1] |
Cross recessed screw
|
L=25mm
|
| 47. |
834481
|
[5] |
Gasket
|
|
| 48. |
89865
|
[1] |
Gasket
|
|
| 49. |
834480
|
[1] |
Flange
|
|
| 50. |
|
|
|
|
