| 1. |
862490
|
[1] |
Housing
|
|
| 2. |
949918
|
[2] |
Shut-off cock
|
|
| 3. |
849031
|
[1] |
Cap
|
|
| 4. |
842137
|
[1] |
Gasket
|
|
| 5. |
864311
|
[1] |
Retainer
|
|
| 5A. |
864382
|
[1] |
Coolant pipe, charge air cooler
|
|
| 5B. |
864559
|
[1] |
Clamp
|
|
| 5C. |
976944
|
[1] |
Washer
|
(966674)
|
| 5D. |
944926
|
[1] |
Flange screw
|
|
| 5E. |
849576
|
[1] |
Pipe elbow, sea water pump
|
For engine mounted heat exchanger with fresh-water-cooled charge-air-cooler
|
| 6. |
863209
|
[2] |
Sealing ring
|
|
| 7. |
946173
|
[8] |
Flange screw
|
|
| 8. |
849342
|
[1] |
Coolant pipe
|
For MG516 replaced by 1pc coolant pipe 866772, 1pc coolant pipe 866773, 4pcs clamp 961673 and 190mm
|
| 8A. |
866772
|
[1] |
Coolant pipe
|
SN1101050802/XXXXX-
|
| 8B. |
863294
|
[1] |
Pipe elbow
|
Aux
|
| 8C. |
842867
|
[1] |
Flange
|
Aux
|
| 9. |
849401
|
[2] |
Clamp, induction manifold
|
|
| 10. |
965178
|
[2] |
Flange screw
|
|
| 11. |
843584
|
[1] |
Gasket
|
|
| 12. |
823661
|
[2] |
Zinc anode
|
|
| 13. |
836169
|
[2] |
Gasket
|
|
| 14. |
823662
|
[2] |
Plug
|
|
| 15. |
955373
|
[2] |
Hexagon screw
|
|
| 16. |
941912
|
[2] |
Spring washer
|
|
| 17. |
946472
|
[3] |
Flange screw
|
|
| 18. |
955977
|
[2] |
O-ring
|
|
| 19. |
3825961
|
[1] |
Heat exchanger
|
(849884)
|
| 20. |
925276
|
[1] |
O-ring, heat exchanger insert
|
|
| 21. |
925278
|
[3] |
O-ring
|
|
| 22. |
950529
|
[2] |
Pin
|
|
| 23. |
849032
|
[1] |
Cap
|
|
| 24. |
849053
|
[1] |
Bracket
|
|
| 25. |
946472
|
[4] |
Flange screw
|
|
| 26. |
965190
|
[4] |
Flange screw
|
|
| 27. |
925079
|
[1] |
O-ring
|
|
