| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 242872 | [1] | Centrifugal governor | |
| 2. | ||||
| 3. | 242437 | [1] | Gasket | |
| 4. | 236316 | [1] | Gasket | |
| 5. | 242439 | [3] | Stud | |
| 6. | 941906 | [3] | Spring washer | |
| 7. | 236668 | [4] | Nut | |
| 8. | 242232 | [4] | Screw | |
| 9. | ||||
| 10. | 236652 | [7] | Screw | |
| 11. | 236695 | [4] | Gasket | |
| 12. | 236195 | [1] | Plug | |
| 13. | 242641 | [1] | Washer | |
| 14. | 242830 | [1] | Pin | |
| 15. | 242440 | [1] | Cover | |
| 16. | 242441 | [1] | Screw | |
| 17. | 242442 | [1] | Nut | |
| 18. | 242637 | [1] | Set screw | |
| 19. | 242629 | [1] | Adjusting washer | TH=0.1mm |
| 19. | 242630 | [1] | Adjusting washer | TH=0.2mm |
| 19. | 242444 | [1] | Washer | TH=0.3mm |
| 20. | 78378 | [2] | Lock washer | |
| 21. | 242631 | [1] | Washer | |
| 22. | 242446 | [2] | Retainer | |
| 23. | 125024 | [2] | Seal | |
| 24. | ||||
| 25. | 242831 | [1] | Spring | |
| 26. | 242636 | [1] | Lever | |
| 27. | 910115 | [1] | Woodruff key | |
| 28. | 242069 | [1] | Spring washer | |
| 29. | 242070 | [1] | Nut | |
| 30. | 242638 | [1] | Screw | |
| 31. | 242632 | [1] | Washer | |
| 32. | ||||
| 33. | ||||
| 34. | 242465 | [1] | Nut | |
| 35. | ||||
| 36. | 242881 | [1] | Link | |
| 37. | ||||
| 38. | 242452 | [1] | Lever | |
| 39. | 236789 | [1] | Split pin | |
| 40. | 242235 | [1] | Shaft | |
| 41. | 242453 | [1] | Block | |
| 42. | ||||
| 43. | 236089 | [1] | Shaft | |
| 44. | ||||
| 45. | ||||
| 46. | 236320 | [2] | Gasket | |
| 47. | 236333 | [1] | Shaft | |
| 48. | 242454 | [1] | Cover | |
| 49. | ||||
| 50. | 236110 | [1] | Gasket | |
| 51. | 242241 | [4] | Screw | |
| 52. | 941906 | [4] | Spring washer | |
| 53. | 242457 | [1] | Washer | |
| 54. | 242104 | [1] | Nut | |
| 55. | 236791 | [2] | Lever | |
| 56. | 236730 | [1] | Eccentric shaft | |
| 57. | 236736 | [1] | Sealing ring | |
| 58. | 242075 | [1] | Bearing flange | |
| 59. | 242077 | [1] | Adjusting screw | |
| 60. | 242712 | [1] | Screw | |
| 61. | 242455 | [2] | Nut | |
| 62. | 242078 | [1] | Stop ring | |
| 63. | ||||
| 64. | 242079 | [1] | Lever | |
| 65. | 236685 | [1] | Screw | |
| 66. | 941906 | [1] | Spring washer | |
| 67. | 242833 | [1] | Piston | |
| 68. | ||||
| 69. | 236740 | [1] | Adjusting screw | |
| 70. | ||||
| 71. | 236348 | [1] | Spring | |
| 72. | 242633 | [1] | Washer | |
| 73. | ||||
| 74. | 236353 | [1] | Adjusting screw | |
| 75. | 242714 | [1] | Gasket | |
| 76. | 955270 | [1] | Hexagon screw | |
| 77. | 242054 | [1] | Spring washer | |
| 78. | 236726 | [1] | Cube | |
| 79. | 236101 | [2] | Adjusting nut | |
| 80. | 236383 | [2] | Spring disc | |
| 81. | 236021 | [2] | Spring | |
| 82. | 808293 | [2] | Spring | |
| 83. | 236115 | [2] | Spring | |
| 84. | 236114 | [2] | Washer | |
| 85. | 236384 | [2] | Spring disc | |
| 86. | 236069 | [2] | Washer | |
| 87. | 236654 | [1] | Regulator weight | |
| 88. | 242068 | [1] | Governor | |
| 89. | 236305 | [1] | Angle lever | |
| 90. | 236116 | [2] | Bushing | |
| 91. | 236658 | [2] | Bushing | |
| 92. | 236706 | [1] | Angle lever | |
| 93. | 236116 | [2] | Bushing | |
| 94. | 236658 | [2] | Bushing | |
| 95. | 236098 | [1] | Shaft | |
| 96. | 236097 | [2] | Shaft | |
| 97. | 236102 | [4] | Shaft | |
| 98. | 236103 | [4] | Lock ring | |
| 99. | ||||
| 100. | 236719 | [1] | Striker plate | |
| 101. | 242836 | [2] | Washer | |
| 102. | 236109 | [1] | Lock washer | |
| 103. | 242837 | [1] | Lock ring | |
| 104. | 242072 | [4] | Absorber | |
| 105. | 242071 | [1] | Sleeve | |
| 106. | 236787 | [1] | Sleeve | |
| 107. | ||||
| 108. | ||||
| 109. | TH=2,23mm | |||
| 109. | 242099 | [1] | Spacer washer | TH=2,07mm |
| 109. | 242100 | [1] | Spacer washer | TH=2,15mm |
| 110. | 236712 | [1] | Pin | |
| 111. | 236711 | [1] | Spring | |
| 112. | 236710 | [1] | Spring | |
| 113. | 236708 | [1] | Sleeve | |
| 114. | ||||
| 115. | 236203 | [1] | Lock pin | |
| 116. | ||||
| 117. |
