| 1. |
|
|
|
|
| 1. |
954443
|
[1] |
Electric cable, 5 sq mm black
|
|
| 1. |
954444
|
[1] |
Electric cable, 5 sq mm brown
|
|
| 1. |
954445
|
[1] |
Electric cable, 5 sq mm red
|
|
| 1. |
954446
|
[1] |
Electric cable, 5 sq mm yellow
|
|
| 1. |
954447
|
[1] |
Electric cable, 5 sq mm green
|
|
| 1. |
954448
|
[1] |
Electric cable, 5 sq mm blue
|
|
| 1. |
954449
|
[1] |
Electric cable, 5 sq mm grey
|
|
| 1. |
954450
|
[1] |
Electric cable, 5 sq mm ivory
|
|
| 1. |
961795
|
[1] |
Electric cable, 5 sq mm ivory/ blue
|
|
| 1. |
954451
|
[1] |
Electric cable, 5 sq mm black
|
|
| 1. |
954452
|
[1] |
Electric cable, 5 sq mm brown
|
|
| 1. |
954453
|
[1] |
Electric cable, 5 sq mm red
|
|
| 1. |
954455
|
[1] |
Electric cable, 5 sq mm green
|
|
| 1. |
954456
|
[1] |
Electric cable, 5 sq mm blue
|
|
| 1. |
954458
|
[1] |
Electric cable, 5 sq mm ivory
|
|
| 1. |
954461
|
[1] |
Electric cable
|
|
| 1. |
954464
|
[1] |
Electric cable
|
|
| 1. |
954465
|
[1] |
Electric cable
|
|
| 1. |
954467
|
[1] |
Electric cable
|
|
| 1. |
954469
|
[1] |
Electric cable
|
|
| 1. |
954471
|
[1] |
Electric cable
|
|
| 1. |
954485
|
[1] |
Electric cable
|
|
| 1. |
954500
|
[1] |
Electric cable
|
|
| 1. |
954502
|
[1] |
Electric cable
|
|
| 2. |
185501
|
[1] |
Hose
|
D=9mm, i.d=8mm
|
| 2. |
185504
|
[1] |
Hose
|
D=11,5mm, i.d=8mm
|
| 2. |
185506
|
[1] |
Hose
|
D=6mm, i.d=5mm
|
| 2. |
185507
|
[1] |
Hose
|
D=11mm, i.d=10mm
|
| 2. |
185508
|
[1] |
Hose
|
D=16mm, i.d=14mm
|
| 2. |
185509
|
[1] |
Outer casing
|
D=19mm, i.d=15mm
|
| 3. |
948210
|
[1] |
Cable tie
|
(827353) nylon
|
| 3. |
335146
|
[1] |
Cable tie
|
Al
|
| 4. |
|
|
|
|
| 4. |
942659
|
[1] |
Terminal block
|
|
| 4. |
942660
|
[1] |
Terminal block
|
|
| 4. |
942558
|
[1] |
Terminal block
|
|
| 4. |
942661
|
[1] |
Terminal block
|
|
| 4. |
942662
|
[1] |
Terminal block
|
|
| 5. |
182010
|
[1] |
Coupling piece
|
Max 15mm²
|
| 5. |
190128
|
[1] |
Coupling piece
|
Max 15mm²
|
| 5. |
190476
|
[1] |
Coupling piece
|
Max 15mm²
|
| 5. |
182008
|
[1] |
Coupling piece
|
Max 15mm²
|
| 5. |
941412
|
[1] |
Coupling piece
|
Max 20mm²
|
| 6. |
956924
|
[1] |
Cable terminal
|
Pour section cable 0,5-1,5 millimetre-carre, I.d=3,7mm D=5,6mm
|
| 7. |
881516
|
[1] |
Cable terminal
|
Pour section cable 0,5-1,5 millimetre-carre, I.d=3,5mm D=5,5mm
|
| 7. |
881492
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=4,3mm D=8,7mm
|
| 7. |
881493
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=5,2mm D=8,7mm
|
| 7. |
881508
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=6,7mm D=11,9mm
|
| 7. |
881494
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=8,3mm D=11,9mm
|
| 7. |
881504
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=10,5mm D=15,9mm
|
| 7. |
881506
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=4,3mm D=9,5mm
|
| 7. |
881495
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=5,2mm D=9,5mm
|
| 7. |
881496
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=6,7mm D=12,7mm
|
| 7. |
881497
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=8,3mm D=12,7mm
|
| 7. |
881498
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=10,5mm D=15,4mm
|
| 7. |
881500
|
[1] |
Cable terminal
|
For cable area 10,5-16,0mm²., I.d=5,2mm D=15,9mm
|
| 7. |
881501
|
[1] |
Cable terminal
|
For cable area 10,5-16,0mm²., I.d=6,7mm D=15,9mm
|
| 7. |
881502
|
[1] |
Cable terminal
|
For cable area 10,5-16,0mm²., I.d=8,3mm D=15,9mm
|
| 7. |
940337
|
[1] |
Cable terminal, terminal
|
For cable area 10,5-16,0mm²., (881507)
|
| 7. |
|
|
|
I.d=10,5mm D=15,9mm
|
| 7. |
949591
|
[1] |
Cable terminal
|
For cable area 6,5-10,5mm²., I.d=4,3mm D=8mm
|
| 8. |
881483
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., L=7,7mm b=7,6mm
|
| 8. |
881484
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., L=7,7mm b=7,6mm
|
| 9. |
881485
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., L=7,7mm b=7,6mm
|
| 9. |
881486
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., L=7,7mm b=7,6mm
|
| 9. |
|
|
|
For cable area 0,75-2,0mm²., L=7,7mm b=7,6mm
|
| 10. |
|
|
|
Pour section cable 0,5-1,5 millimetre-carre, L=6,2mm b=5,6mm
|
| 11. |
881491
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., L=7,7mm b=7,6mm
|
| 12. |
881487
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., L=15,7mm b=6,3mm
|
| 12. |
881488
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., L=15,7mm b=6,3mm
|
| 13. |
881518
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., L=10mm b=6,3mm
|
| 14. |
881509
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=4,4mm D=9,8mm
|
| 14. |
881505
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=5,2mm D=8,7mm
|
| 14. |
881511
|
[1] |
Cable terminal
|
For cable area 3,0-6,0mm²., I.d=4,4mm D=8mm
|
| 15. |
942429
|
[1] |
Cable terminal
|
For cable area 1,5-2,5mm²., I.d=1,8mm L=14,4mm
|
| 15. |
|
|
|
For cable area 3,0-6,0mm²., D=2,6mm L=20,6mm
|
| 16. |
956956
|
[1] |
Splice
|
Pour section cable 0,5-1,5 millimetre-carre, L=26mm
|
| 16. |
956958
|
[1] |
Splice
|
For cable area 1,5-2,5mm²., L=26mm
|
| 16. |
956960
|
[1] |
Splice
|
For cable area 3,0-6,0mm²., L=28mm
|
| 17. |
829311
|
[1] |
Tab
|
I.d=5,2mm b=6,35mm
|
| 18. |
959046
|
[1] |
Housing
|
I.d=9mm
|
| 19. |
76614
|
[1] |
Rubber collar
|
|
| 19. |
841234
|
[1] |
Rubber collar
|
|
| 20. |
673580
|
[1] |
Terminal cap
|
|
| 21. |
941269
|
[1] |
Plug
|
D=25mm
|
| 22. |
958213
|
[1] |
Housing
|
|
| 23. |
958212
|
[1] |
Housing
|
|
| 24. |
941104
|
[1] |
Housing
|
|
| 25. |
941105
|
[1] |
Housing
|
|
| 26. |
945830
|
[1] |
Housing
|
|
| 27. |
945831
|
[1] |
Tab housing
|
|
| 28. |
1214948
|
[1] |
Housing
|
|
| 29. |
949181
|
[1] |
Receptacle housing
|
|
