| 1. |
7742090_047
|
|
dynamo and installation comps
|
|
| 1. |
|
|
|
|
| 2. |
833456
|
[1] |
Alternator
|
|
| 3. |
|
|
|
Replaced by 833669., MO-17000
|
| 3. |
833669
|
[1] |
Starter motor
|
MO 17001-41790
|
| 3. |
3803073
|
[1] |
Starter motor, exch
|
MO 17001-41790
|
| 4. |
833335
|
[1] |
Bracket
|
|
| 5. |
946928
|
[1] |
Stud
|
See group 2A
|
| 6. |
946075
|
[1] |
Washer
|
|
| 7. |
963107
|
[1] |
Lock nut
|
|
| 8. |
955344
|
[2] |
Hexagon screw
|
|
| 9. |
940280
|
[2] |
Spring washer
|
|
| 10. |
955784
|
[2] |
Hexagon nut
|
|
| 11. |
941907
|
[1] |
Spring washer
|
|
| 12. |
955782
|
[1] |
Hexagon nut
|
|
| 13. |
|
|
|
Replaced by 834693 + 834694.
|
| 13. |
834693
|
[1] |
Charge regulator
|
|
| 13. |
834694
|
[1] |
Starter relay
|
|
| 14. |
870730
|
[1] |
Actuator solenoid
|
Starter cut-out relay for unlimited battery capacity.
|
| 15. |
239964
|
[1] |
Governor
|
Starter cut-out relay for unlimited battery capacity.
|
| 16. |
807078
|
[1] |
Pressure monitor
|
|
| 16A. |
945612
|
[1] |
Nipple
|
MDZB spec 867122, -144, -145, MD2HY spec 867151, AQD2B spec 867152
|
| 17. |
955945
|
[1] |
Toothed washer
|
|
| 18. |
190663
|
[1] |
Screw
|
|
| 19. |
840074
|
[1] |
Temperature sensor
|
|
| 20. |
18840
|
[1] |
Gasket
|
|
| 21. |
1502028
|
[1] |
Tachometer sensor
|
|
| 22. |
957181
|
[1] |
Gasket
|
|
| 23. |
819678
|
[1] |
Instrument plate
|
MO-15237
|
| 24. |
833622
|
[1] |
Instrument panel
|
Replaced by 833908., MO 15238-28200
|
| 24. |
833908
|
[1] |
Instrument panel
|
Replaced by 840529., MO 28201-55699
|
| 25. |
833608
|
[1] |
Cable block
|
For engine with dynamo.
|
| 25. |
833612
|
[1] |
Cable block
|
For engine with alternator and starter motor
|
| 26. |
833618
|
[1] |
Cable block
|
L=2000mm
|
| 26. |
833619
|
[1] |
Cable block
|
L=5000mm
|
| 27. |
|
|
|
MO-15237
|
| 28. |
7742090_057
|
|
cables and terminals
|
|
| 29. |
827940
|
[1] |
Alarm kit
|
See group 9
|
| 30. |
840013
|
[1] |
Instrument panel
|
|
| 30. |
|
|
|
|
| 31. |
839128
|
[1] |
Plastic plug
|
|
| 32. |
944540
|
[4] |
Screw
|
|
| 33. |
834397
|
[1] |
Voltmeter
|
|
| 34. |
834374
|
[1] |
Voltmeter
|
|
| 35. |
19923
|
[1] |
Bulb
|
|
| 36. |
808175
|
[1] |
Bulb socket
|
|
| 37. |
840228
|
[1] |
Temperature gauge ki
|
MO-15237
|
| 38. |
841233
|
[1] |
Thermometer
|
(831475)
|
| 39. |
19923
|
[1] |
Bulb
|
|
| 40. |
808174
|
[1] |
Bulb socket
|
|
| 41. |
840074
|
[1] |
Temperature sensor
|
|
| 42. |
957181
|
[1] |
Gasket
|
|
| 43. |
|
|
|
MO-15237
|
| 44. |
836467
|
[1] |
Tachometer
|
|
| 45. |
19923
|
[1] |
Bulb
|
|
| 46. |
808175
|
[1] |
Bulb socket
|
|
| 47. |
1502028
|
[1] |
Tachometer sensor
|
|
| 48. |
957181
|
[1] |
Gasket
|
|
| 49. |
941950
|
[1] |
Clamp
|
|
| 50. |
948210
|
[1] |
Cable tie
|
(827353)
|
| 51. |
824823
|
[1] |
Fuse box
|
|
| 52. |
870980
|
[1] |
Main switch
|
|
| 53. |
243700
|
[1] |
Handle
|
|
| 53A. |
955783
|
[2] |
Hexagon nut
|
|
| 54. |
821042
|
[1] |
Sign
|
|
| 55. |
834400
|
[1] |
Tank gauge
|
|
| 55. |
|
|
|
See group 9
|
