| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 28V 25A | |||
| 2. | See group 2A | |||
| 3. | 7742190_112 | thermoswitch and protecting box with installation comps | ||
| 4. | 7742190_114 | starter casing with installation comps | ||
| 5. | 823480 | [1] | Charge regulator | Bröyt spec. 867510., 24V 25A |
| 6. | 899709 | [3] | Vibration damper | |
| 7. | 956091 | [3] | Cross recessed screw | |
| 8. | 941906 | [6] | Spring washer | |
| 9. | 956092 | [3] | Cross recessed screw | |
| 10. | 870998 | [1] | Starter motor | 24V repl by 847308 |
| 10. | 847308 | [1] | Starter motor | 24V |
| 10. | ||||
| 11. | 953486 | [3] | Stud | |
| 12. | 942336 | [3] | Spring washer | |
| 13. | 955827 | [3] | Hexagon nut | |
| 14. | 1507899 | [1] | Tachometer sensor | |
| 15. | 76614 | [2] | Rubber collar | |
| 16. | 823486 | [1] | Intermediate section | |
| 17. | 823487 | [1] | Cover | |
| 18. | 823490 | [1] | Gasket | |
| 19. | 823488 | [2] | Spacer screw | |
| 20. | 950363 | [2] | Lock nut | |
| 21. | 881192 | [1] | Grommet | |
| 22. | 940135 | [3] | Hexagon screw | |
| 23. | 941907 | [3] | Spring washer | |
| 24. | 16325 | [3] | Plug | |
| 25. | 180110 | [1] | Elbow nipple | |
| 26. | 334175 | [1] | Hose assembly | |
| 27. | 955826 | [3] | Hexagon nut | |
| 28. | 843812 | [1] | Contact | Stop |
| 29. | 843813 | [1] | Contact | Alarm |
| 30. | 881432 | [1] | Sensor | |
| 31. | 836273 | [1] | Cock | |
| 32. | 837718 | [1] | Runaway monitor | |
| 33. | 837003 | [1] | Spacer screw | |
| 34. | 824411 | [1] | Clutch housing | |
| 35. | 836366 | [1] | Cover | |
| 36. | 836368 | [1] | Bracket | |
| 37. | 836367 | [1] | Bracket | |
| 38. | 836760 | [1] | Bracket | |
| 39. | 239883 | [3] | Relay | |
| 40. | 836177 | [3] | Current bar | |
| 41. | 824159 | [40] | Clamp | |
| 42. | 824160 | [5] | Clamp | Early type |
| 43. | 824161 | [1] | Bracket | |
| 44. | 824172 | [2] | End plate | |
| 45. | 824173 | [2] | Bracket | |
| 46. | 842730 | [1] | Sealing strip | L=1420mm |
| 47. | 955284 | [2] | Hexagon screw | |
| 48. | 941905 | [5] | Spring washer | |
| 49. | 956076 | [5] | Cross recessed screw | |
| 50. | 955780 | [5] | Hexagon nut | |
| 51. | 956061 | [2] | Cross recessed screw | |
| 52. | 941904 | [2] | Spring washer | |
| 53. | 955779 | [2] | Hexagon nut | |
| 54. | 941906 | [2] | Spring washer | |
| 55. | 662620 | [2] | Rubber button | AQ290A MO-20459. |
| 56. | 941912 | [1] | Spring washer | |
| 57. | 940133 | [4] | Hexagon screw | |
| 58. | 942336 | [4] | Spring washer | |
| 59. | 955827 | [4] | Hexagon nut | |
| 60. | 940135 | [1] | Hexagon screw | |
| 61. | 941907 | [1] | Spring washer | |
| 62. | Can't be used on alternator 841765. | |||
| 63. | 655545 | [3] | Rubber button | AQ290A MO 20460-. |
| 64. | 94081 | [6] | Plug | |
| 65. | 955900 | [2] | Washer | |
| 66. | 881192 | [5] | Grommet | |
| 67. | 881193 | [2] | Grommet | |
| 68. | 880243 | [5] | Nut | |
| 69. | 880755 | [2] | Nut | |
| 70. | 88578 | [2] | Fuse box | |
| 71. | 943905 | [2] | Fuse, blue | 25A |
| 71. | 942785 | [2] | Fuse | 16A |
| 72. | 956076 | [4] | Cross recessed screw | |
| 73. | 941905 | [4] | Spring washer | |
| 74. | 955780 | [4] | Hexagon nut | |
| 75. | ||||
| 76. | ||||
| 77. | 335146 | [1] | Cable tie | |
| 78. | 948210 | [1] | Cable tie | (827353) |
| 79. | 837619 | [1] | Attaching plate | |
| 80. | 837620 | [1] | Attaching plate | |
| 81. | 241608 | [1] | Protetective sleeve | |
| 82. | 952627 | [2] | Clamp | |
| 83. | 950047 | [2] | Cross recessed screw | |
| 84. | 955825 | [2] | Hexagon nut | |
| 85. | ||||
| 86. | 950158 | [3] | Cross recessed sunk | Replaced by 1pc alternator 841989 and 1pc PULLby 829312. |
