| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | ZM2814571 | [1] | Hydraulic pump | |
| 10. | VOE15105558 | [2] | Plug | M26x1,5 |
| 12. | ZM2289691 | [1] | Screw | |
| 13. | ZM2161050 | [1] | Nut | M12x1,5 |
| 14. | VOE11702439 | [1] | Pump element | |
| 15. | ZM2289510 | [1] | Shaft | |
| 16. | VOE11708243 | [2] | Snap ring | 80x2,5 |
| 17. | ZM2906525 | [1] | Gasket | 45x80x7 |
| 19. | ZM2160960 | [1] | Roller bearing | 40x80x23 |
| 20. | ZM7094960 | [1] | Snap ring | 40x1,75 |
| 21. | VOE11709578 | [1] | Bearing race | |
| 2. | VOE11702857 | [1] | Plug | M10x1 |
| 22. | VOE11708649 | [1] | Bearing shell kit | |
| 23. | VOE11709907 | [2] | Wire | |
| 25. | ZM2902114 | [1] | Rocker arm | |
| 26. | ZM2289523 | [1] | Wedge | |
| 28. | ZM2906521 | [1] | Plate | |
| 29. | ZM2906522 | [1] | Ball | |
| 30. | ZM2906520 | [1] | Spring kit | |
| 31. | ZM2290228 | [1] | Washer | 0,6 mm |
| 31. | ZM2290227 | [REQ] | Washer | 0,8 mm |
| 31. | ZM2290226 | [REQ] | Washer | 1,0 mm |
| 3. | ZM2903402 | [2] | Pivot pin | |
| 31. | ZM2290225 | [REQ] | Washer | 1,2 mm |
| 32. | VOE15166357 | [9] | Piston | |
| 33. | ZM2906519 | [1] | Cylinder | |
| 34. | ZM2906524 | [2] | Disc | |
| 35. | ZM2289518 | [1] | Spring | |
| 36. | ZM7094965 | [1] | Snap Ring | 45x1,75 |
| 37. | ZM2906516 | [1] | Tilting | |
| 38. | ZM2906527 | [1] | Cover | |
| 39. | ZM7098064 | [1] | Nut | BM12x1,5 |
| 40. | ZM7096555 | [8] | Screw | M6x20 |
| 4. | VOE15103769 | [3] | Plug | M18x1,5 |
| 41. | VOE11997660 | [2] | O-ring | 69,52x2,62 |
| 42. | ZM2906526 | [1] | Piston, cpl. | |
| 43. | ZM2906531 | [1] | Piston | |
| 44. | ZM2906532 | [1] | Rod | |
| 45. | ZM2119000 | [1] | O-ring | 9,25x1,78 |
| 46. | ZM2906506 | [2] | Ring | |
| 47. | ZM2906504 | [2] | Ring | 5,67 mm |
| 47. | ZM2906505 | [REQ] | Ring | 5,72 mm |
| 47. | ZM2906498 | [REQ] | Ring | 5,77 mm |
| 47. | ZM2906499 | [REQ] | Ring | 5,82 mm |
| 5. | VOE15103768 | [4] | Plug | M12x1,5 |
| 47. | ZM2906500 | [REQ] | Ring | 5,87 mm |
| 47. | ZM2906501 | [REQ] | Ring | 5,92 mm |
| 47. | ZM2906502 | [REQ] | Ring | 5,97 mm |
| 47. | ZM2906503 | [REQ] | Ring | 6,02 mm |
| 48. | ZM2906542 | [2] | Stop plate | |
| 49. | ZM2906533 | [2] | Spring plate | |
| 50. | ZM2289541 | [2] | Spring | |
| 51. | ZM2901312 | [2] | Spring | |
| 52. | ZM2289542 | [2] | Spring | |
| 53. | ZM2289546 | [2] | Ring | |
| 6. | VOE15179596 | [2] | Pin | 3x10 |
| 54. | VOE11707070 | [2] | Sealing ring | |
| 55. | ZM2906529 | [2] | Guide ring | |
| 56. | ZM2906528 | [1] | Cover | |
| 57. | VOE15110111 | [1] | Gear pump | |
| 58. | ZM2906538 | [1] | Wear plate | |
| 59. | ZM2906540 | [1] | Flange | |
| 60. | ZM8097916 | [4] | Screw | M10x40 |
| 61. | ZM2289688 | [1] | Ring | A38 |
| 62. | ZM2906541 | [1] | Shaft | |
| 63. | VOE11997671 | [2] | O-ring | 88,57x2,62 |
| 7. | ZM2270310 | [1] | Contact breaking plug | M6 |
| 64. | ZM2901336 | [1] | Spring | |
| 65. | VOE11709539 | [1] | Pump rotor | |
| 66. | ZM2902986 | [1] | Bearing bushing | |
| 67. | VOE15110118 | [1] | O-ring | |
| 68. | ZM3401420 | [2] | Screw | M16x50 |
| 69. | VOE11305062 | [2] | Washer | B18 |
| 70. | ZM2817021 | [1] | Connection flange | |
| 71. | VOE984079 | [17] | Hex. socket screw | M10x25 |
| 72. | VOE11306537 | [1] | Clutch | |
| 73. | ZM2289709 | [1] | Flange | |
| 8. | ZM2161750 | [1] | Screw | M14x1,5 |
| 74. | ZM2289707 | [1] | End washer | |
| 75. | ZM2289708 | [1] | Screw | M12x30 |
| 9. | VOE15103769 | [1] | Plug | M18x1,5 |
