| . . | 24100J1638F2 | [1] | IDLER | KOB, Serial Range: LR.0143—-0157 |
| . . | 24100J1638F3 | [1] | IDLER WHEEL | KOB, Start Serial: LR.0158— |
| 2. | 2416N1239D1 | [1] | BLOCK | KOB |
| 3. | 2416N1239D2 | [1] | BLOCK | KOB |
| 4. | 2410P456 | [1] | ROLLER SHAFT | KOB |
| 5. | 2418P3375 | [1] | PLATE | |
| 7. | R45P0018D16 | [2] | SEAL | KOB Superseded by part number: ZD57F15040 |
| 8. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 9. | ZS23C20080 | [4] | SCREW,Hex Socket Head, M20 x 80mm | KOBM20x2.5x80mm |
| 10. | ZD11G09500 | [2] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOBID 94.40 ± 0.81 x OD 100mm |
| 11. | 2405P212 | [2] | BUSHING | KOB |
| 13. | 2413J239 | [1] | IDLER, Serial Range: LR.0143—-0157 | |
| 14. | 2419T2669D2 | [2] | PIN | KOBOD 20 x 137mm Long |
| 15. | 2413N316 | [1] | IDLER, Start Serial: LR.0158\u2014 | IDLER, Start Serial: LR.0158— |
