| . . | 24100J6701F1 | [1] | WIRING ASSY, ELEC | WIRING ASSY, ELEC |
| 1. | 2456R123D2 | [2] | LIGHT | KOB Superseded by part number: 2456R123D3 |
| 2. | 2479U142 | [1] | RELAY | KOB |
| 3. | B00P0001F1 | [1] | WIPER | KOB |
| 3-1. | R79P0020D1 | [1] | WIPER MOTOR | KOB Superseded by part number: 2456R8D25 |
| 3-2. | R79P0022 | [1] | WIPER ARM | KOB |
| 3-3. | R79P0021 | [1] | WIPER BLADE | KOB Superseded by part number: 2488Z8D3 |
| 3-4. | ZS31C06010 | [6] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm |
| 3-5. | ZW22X06000 | [6] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 4. | 2479U255 | [1] | ANTENNA | KOB |
| 5. | 2456R117F2 | [1] | LIGHT | KOB |
| 5-4. | 4056R4F1 | [1] | LAMP | KOB |
| 5-4G. | 4056Z19D1 | [1] | LIGHT | KOB |
| 5-5. | 2456R117S5 | [1] | SWITCH | KOB |
| 5-6. | 2456R117S6 | [1] | BRACKET | |
| 5-7. | ZS41C04008 | [2] | CAPSCREW,M4 x 8mm | KOBSCREW M04x0.7x08mm |
| 6. | 2420Z699 | [1] | GROMMET | KOB |
| 7. | 2432Z270 | [6] | CLAMP | KOB |
| S. | ZN16C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 9. | ZW26X06000 | [6] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 10. | 2432Z309D1 | [10] | CLAMP | KOB |
| 11. | 2432Z290 | [10] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 12. | R16P0036D16 | [5] | CLAMP | |
| 13. | R16P0036D11 | [4] | CLAMP | |
| 14. | ZS31C06010 | [2] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm |
| 15. | ZS11C10020 | [1] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 16. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 17. | ZN11C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 18. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 19. | ZS11C12016 | [1] | SCREW,Hex, M12 x 16mm, Cl 4.8 | KOBM12x1.75x16mm Superseded by part number: ZS18C12018 |
| 20. | ZW22X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 21. | ZN16C10008 | [11] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 22. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 23. | 2479R656 | [1] | WIRE HARNESS | KOBCODE |
| 24. | 2479N199 | [1] | HARNESS(NO LONGER AVL.) | HARNESS(NO LONGER AVL.) |
| 25. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 26. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 27. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 28. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 29. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 30. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 31. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 32. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 33. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 34. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 35. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
| 36. | NSS | [1] | NOT SOLD SEPARAT | CONHARNESS |
