| . . | 24100X1119F2 | [1] | HYDR LINES, UPP | |
| 5. | 2418T7524 | [1] | TUBE | TUBE |
| 6. | 2418T7525 | [1] | TUBE | TUBE |
| 7. | 2418P7065 | [1] | TUBE | TUBE |
| 8. | 2418P7066 | [1] | TUBE | TUBE |
| 9. | 2418P7067 | [1] | TUBE | TUBE |
| 10. | 2418P6281 | [1] | TUBE | TUBE |
| 11. | 2418P7065 | [1] | TUBE | TUBE |
| 13. | 2418P7071 | [1] | TUBE | TUBE |
| 14. | B36P0049F3 | [1] | CHECK VALVE | KOB |
| 15. | 2418T7003D2 | [2] | FLEXIBLE HOSE | KOB |
| 16. | 2420R483D1 | [2] | HOSE | KOB |
| 17. | R18P0168D34 | [1] | HOSE | KOB |
| 18. | R18P0168D6 | [2] | HOSE | KOB |
| 19. | R44P0089D11 | [4] | COUPLING | KOB Superseded by part number: ZG15F03200 |
| 19-3. | R44P0089D11S3 | [8] | GASKET | KOB |
| 20. | ZX21M12056 | [1] | HOSE | KOB560mm Long (22-3/64 in) Superseded by part number: ZX21M12060 |
| 22. | R44T0203 | [2] | CONNECTOR | CONNECTOR |
| 23. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB45° -- 3/4" PF (Incls. O-Ring 237-6012) |
| 24. | ZE13X16000 | [4] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 25. | ZD11G04500 | [2] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 26. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 27. | ZD12P02240 | [2] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 28. | ZD12P02900 | [2] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 32. | ZC15X06000 | [8] | CLIP | KOB |
| 33. | ZC15X03600 | [11] | CLIP | KOB |
| 37. | ZS16C10000 | [1] | WASHER | KOB |
| 40. | ZN16C10008 | [1] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 42. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 43. | ZW26X12000 | [26] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 44. | ZW22X16000 | [6] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 46. | ZN16C12010 | [7] | NUT | KOB Superseded by part number: ZN18C12010 |
| 47. | 2432T1699 | [3] | CLAMP | CLAMP |
| 48. | ZC26X32014 | [3] | CLAMP | |
| 49. | ZS16C12060 | [3] | CAPSCREW M12x1.75x60mm | CAPSCREW M12x1.75x60mm |
| 50. | ZS16C14070 | [2] | BOLT | BOLT |
| 51. | ZN16C14011 | [1] | NUT | KOB Superseded by part number: ZN18C14011 |
| 52. | ZW22X14000 | [2] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 53. | ZS13C12030 | [8] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 54. | ZS13C12040 | [8] | SCREW | KOBM12x1.75x40mm Superseded by part number: ZS18C12040 |
| 55. | ZS13C12045 | [6] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 56. | ZS13C16035 | [6] | SCREW | KOBM16x2.0x35mm |
| 57. | 2418P8320 | [1] | TUBE | |
| 5S. | 2416N2706 | [1] | BRACKET | |
| 59. | 2416N2707 | [1] | BRACKET | |
| 64. | 2436U622F3 | [1] | CONTROL VALVE | KOB |
| 65. | 2436U623F4 | [1] | CONTROL VALVE | KOB |
| 66. | 2432T1762 | [1] | CLAMP | KOBCLAMP |
| 77. | ZF33F28012 | [2] | ELBOW | KOB Superseded by part number: ZA33F28012 |
