| . . | 24100J6244F2 | [1] | ARM ASSY,EXTENSION | |
| 1. | 2411J2739F1 | [1] | ARM, EXTENSION | ARM, EXTENSION |
| 1-10. | 2405P472 | [2] | BUSHING | KOBID 65 x OD 80 x 75mm Long, Flange OD 130 |
| 1-11. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 1-12. | 2405T1078 | [2] | BUSHING | BUSHING |
| 1-13. | 2405T933 | [2] | BUSHING | KOB |
| 1-14. | 2418T8108 | [1] | SPACER | KOB |
| 2. | 2406N734F1 | [1] | LINK | LINK |
| 2-2. | 2405T932 | [3] | BUSHING | KOB |
| 4. | 2406P2720D2 | [1] | LINK, IDLER | LINK, IDLER |
| 7. | 2419P1643 | [1] | PIN | KOB |
| 8. | 2416T13188D2 | [1] | BOSS | BOSS |
| 9. | ZS13C14120 | [3] | SCREW | KOBM14x2.0x120mm Superseded by part number: ZS18C14120 |
| 11. | ZN13C14011 | [6] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 13. | 2445R138D3 | [10] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 14. | 2445R220D2 | [2] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| 15. | ZG91U02000 | [5] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 16. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 17. | 2406P2720D3 | [1] | LINK, IDLER | LINK, IDLER |
| 18. | 2419P1581D2 | [1] | PIN | PIN |
| 19. | 2419P1583D2 | [1] | PIN | KOB |
