神钢零件查询(K905LC) - EXCAVATOR ASN YP1282 (1/85-12/03) (07-001[01]) - BOOM ASSY, 4.6M Kobelco

作者：广数供应链运营团队

浏览数：

时间：2025-01-24 09:52:09

工程机械零件图册查询

Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴

Pos.	Part No	Qty	Parts name	Comments
. .	24100J10758F1	[1]	BOOM ASSY	BOOM ASSY
1.	2411J3614F1	[1]	BOOM	BOOM
1-38.	2405T846	[2]	BUSHING	KOBBUSHING
2.	2418T12645	[1]	PLATE	KOB125 x 420 x Th 9.0mm
3.	2438U973F1	[1]	CYLINDER	KOBBoom Assembly, 4.6M
4.	2418T17973	[1]	TUBE	KOB
5.	2418P19313	[1]	RIGID TUBE	KOB
6.	2418T17974	[1]	TUBE	KOB
7.	2418P18700	[1]	TUBE	KOB
8.	2418P18699	[1]	TUBE	KOB
9.	2418P17860D3	[1]	TUBE	KOB
10.	2418P17860D4	[1]	TUBE	KOB
11.	2418P20944D1	[1]	TUBE	KOB
12.	2418P20944D2	[1]	TUBE	KOB
13.	2418P10041D2	[1]	TUBE	KOB
14.	2444Z2878D1	[2]	FLEXIBLE HOSE	KOB Superseded by part number: 2444R1177D1
15.	2444Z2879D2	[8]	FLEXIBLE HOSE	KOB800mm Long (31-1/2 in) Superseded by part number: 2444R1169D2
16.	2420R349D245	[1]	HOSE	KOB2450mm Long (96-29/64 in)
17.	2420R349D200	[2]	HOSE ASSY.	KOB2000mm Long (78-3/4 in)
18.	ZG91S02000	[2]	LUBE NIPPLE,1/8" NPT x 1/8" NPT	KOB1/8" PT -- Straight
19.	ZG91U02000	[5]	LUBE NIPPLE	KOB90° x 1/8" PT
20.	2419P1654	[1]	PIN	KOB Superseded by part number: 2419P1693
21.	2419P1671D1	[1]	PIN	KOB Superseded by part number: 2419P1699D1
22.	2419T3846	[1]	PIN	KOB Superseded by part number: 2419T6431
23.	2419P1557D1	[1]	PIN	KOB Superseded by part number: 2419P3395D1
24.	2419P1685D1	[2]	PIN	KOB Superseded by part number: 2419P1694D1
25.	2445R138D6	[2]	SEAL,70mm ID x 85.3mm OD x 4mm Thk	KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm
26.	ZH22Z04000	[8]	HYD CONNECTOR	KOB1/4"PTx1/4"PFx37mm Long
27.	B16T0442D10	[2]	SHIM,140mm OD x 77mm ID x 1.2mm Thk	KOBID 77 x OD 140 x Th 1.2mm
28.	B16T0442D11	[2]	SHIM,140mm OD x 77mm ID x 1.6mm Thk	KOBID 77 x OD 140 x Th 1.6mm
29.	B16T0442D12	[2]	SHIM,140mm OD x 77mm ID x 2.3mm Thk	KOBID 77 x OD 140 x Th 2.3mm
30.	2418T12675D1	[2]	COLLAR CLAMP	KOB
31.	ZC26X22011	[4]	CLAMP	KOBSingle Line -- 38x29x65mm Long
32.	2432T2244	[5]	CLAMP	KOBDouble -- 102x32x12mm (Ø23xØ23mm)
33.	2432T2242	[3]	CLAMP	KOBDouble -- 106x38x12mm (Ø23xØ29mm)
34.	2416T3655	[1]	CLAMP	KOB
35.	ZD12P02600	[6]	O-RING	KOBID 25.70 ± 0.26 x OD 32mm
36.	ZS13C14130	[5]	SCREW	KOBM14x2.0x130mm
37.	ZS13C12130	[1]	SCREW	KOBM12x1.75x130mm Superseded by part number: ZS18C12130
38.	ZS13C12045	[3]	SCREW	KOBM12x1.75x45mm Superseded by part number: ZS18C12045
39.	ZS13C10070	[4]	SCREW	KOBM10x1.50x70mm Superseded by part number: ZS18C10070
40.	ZS13C10060	[20]	SCREW	KOBM10x1.50x60mm Superseded by part number: ZS18C10060
41.	ZS13C10045	[5]	SCREW	KOBM10x1.50x45mm Superseded by part number: ZS18C10045
42.	ZS13C10040	[3]	SCREW	KOBM10x1.50x40mm Superseded by part number: ZS18C10040
43.	ZN13C14011	[10]	NUT	KOBM14x2.0mm Superseded by part number: ZN18C14011
44.	ZN13C12010	[2]	NUT	KOBM12x1.75mm Superseded by part number: ZN18C12010
45.	ZN13C06005	[6]	NUT	KOBM06x1.0mm Superseded by part number: ZN18C06005
46.	ZW22X12000	[5]	LOCK WASHER	KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
47.	ZW22X10000	[35]	LOCK WASHER	KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
48.	ZW22X06000	[6]	LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm	LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm
49.	ZS13C10050	[2]	SCREW	KOBM10x1.50x50mm Superseded by part number: ZS18C10050
50.	ZN13C10008	[2]	NUT	KOBM10x1.50mm Superseded by part number: ZN18C10008
51.	2420R349D110	[2]	HOSE,1100.00 mm	KOB1100mm Long (43-19/64 in) Superseded by part number: HX21E04110DX
52.	ZW11X06000	[6]	WASHER	KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450
53.	2432T1333	[1]	CLAMP	KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1
55.	ZC45X11009	[1]	CLIP	KOBClamp, Single Line -- ID 11x35.5mm Long Superseded by part number: ZC46X11009
56.	2438U971F2	[1]	CYLINDER	CYLINDER
57.	2438U972F2	[1]	CYLINDER	KOB
60.	2416T13056	[1]	BRACKET	KOB
61.	ZS13C12030	[2]	CAPSCREW	KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030
64.	2432T1476	[1]	CLAMP	KOB
65.	ZC47X10009	[1]	CLIP	KOB Superseded by part number: ZC48X10009
66.	ZH32X04000	[2]	90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring	KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004)
67.	ZS13C10018	[1]	SCREW	KOBM10x1.50x18mm
68.	B16T0442D1	[6]	SHIM,130mm OD x 72mm ID x 1.2mm Thk	KOBID 72 x OD 130 x Th 1.2mm
69.	B16T0442D2	[6]	SHIM,130mm OD x 72mm ID x 1.6mm Thk	KOBID 72 x OD 130 x Th 1.6mm
70.	B16T0442D5	[6]	SHIM,130mm OD x 72mm ID x 2.3mm Thk	KOBID 72 x OD 130 x Th 2.3mm
71.	B16T0442D44	[1]	SHIM,72mm ID x 130mm OD x 0.9mm Thk	KOBID 72 x OD 130 x Th 0.9mm
