| . . | 24100J11030F1 | [1] | WIRING ASSY, ELEC | |
| 2. | 2479R1368 | [1] | RELAY | KOB |
| 3. | 2456U74F1 | [3] | LIGHT ASSY. | KOBSEE FIG 05-015 Superseded by part number: 2456U74F3 |
| 4. | 2479U1009F1 | [1] | HORN,24V, 390HZ | KOBHigh (415Hz) Superseded by part number: CM53S00002F1 |
| 5. | 2479U1009F2 | [1] | HORN,24V, 350HZ | KOBLow (390Hz) Superseded by part number: CM53S00002F2 |
| 6. | 2486R73D1 | [1] | NEG BATTERY CABLE | KOB |
| 7. | 2486R74D2 | [1] | NEG BATTERY CABLE | KOB |
| 8. | 2486R75D2 | [1] | NEG BATTERY CABLE | KOB |
| 9. | 2486R76D3 | [1] | NEG BATTERY CABLE | KOB |
| 10. | 2479U1112 | [1] | HARNESS | KOB |
| 11. | 2479U1143 | [1] | WIRE HARNESS | KOB |
| 12. | 2479Z1005D2 | [1] | WIRE HARNESS | KOB |
| 13. | 2432Z270 | [5] | CLAMP | KOB |
| 14. | 2420Z1188 | [1] | GROMMET | KOB |
| 15. | 2420Z699 | [1] | GROMMET | KOB |
| 16. | 2420R372D19 | [2] | GROMMET | KOB |
| 17. | 2456U76F1 | [2] | LAMP | KOB |
| 17-1. | 2456U76S1 | [1] | LENS | KOB |
| 17-2. | 2456U76S2 | [1] | BODY | KOB |
| 17-3. | 2456U76S3 | [1] | PACKING | KOB |
| 17-4. | 2456U68S4 | [2] | BULB | KOB Superseded by part number: 2456U85S4 |
| 17-5. | 2456U68S5 | [6] | SCREW | KOB |
| 18. | 2456U76F2 | [2] | LAMP | KOB |
| 18-3. | 2456U76S3 | [1] | PACKING | KOB |
| 18-4. | 2456U68S4 | [2] | BULB | KOB Superseded by part number: 2456U85S4 |
| 18-5. | 2456U68S5 | [6] | SCREW | KOB |
| 18-6. | 2456U76S6 | [1] | LENS | KOB |
| 18-7. | 2456U76S7 | [1] | BODY | KOB |
| 19. | 2456U76F3 | [2] | LAMP | KOB |
| 19-3. | 2456U76S3 | [1] | PACKING | KOB |
| 19-5. | 2456U68S5 | [6] | SCREW | KOB |
| 19-6. | 2456U76S6 | [1] | LENS | KOB |
| 19-8. | 2456U76S8 | [1] | BODY | KOB |
| 20. | 2420Z1227D4 | [24] | SCREW | KOBM06x1.0x20mm |
| 22. | 2432R225D5 | [2] | CLIP | KOB Superseded by part number: ZC46X12011 |
| 23. | 2432R225D6 | [1] | CLIP | KOB |
| 24. | 2432R225D7 | [1] | CLIP | KOB Superseded by part number: ZC46X16011 |
| 25. | 2432R225D8 | [3] | CLIP | KOBClamp, Single -- ID 19.1 x 51.55mm Long Superseded by part number: ZC46X19011 |
| 26. | 2432R225D9 | [1] | CLIP | KOBClamp, Single -- ID 22 x 54mm Long Superseded by part number: ZC46X22011 |
| 27. | 2432R225D8 | [1] | CLIP | KOBClamp, Single -- ID 19.1 x 51.55mm Long Superseded by part number: ZC46X19011 |
| 31. | ZN18C06005 | [5] | NUT | KOBM06x1.0mm |
| 32. | ZW26X06000 | [5] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 36. | ZS18C08030 | [2] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| 37. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 38. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 39. | ZW16K08000 | [2] | WASHER,8mm ID x 15.5mm OD x 1.6mm Thk | KOBID 08 x OD 15.5 x Th 1.6mm |
| 40. | ZS18F10014 | [1] | SCREW | KOBM10x1.25x14mm |
| 42. | ZN18C10008 | [11] | NUT | KOBM10x1.50mm |
| 43. | ZW26X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 44. | ZW16K10000 | [4] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 45. | 2432Z468 | [22] | CLIP | KOB |
| 46. | 2432Z290 | [12] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 47. | 2432Z290D3 | [4] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 48. | 2479Z1798 | [1] | WIRE HARNESS | KOB |
| 49. | 2479Z1799D1 | [1] | WIRE HARNESS | KOB |
