| . . | 24100J6539F3 | [1] | POWER-PLANT | |
| 1. | 2452U387F3 | [1] | RADIATOR | KOBSEE FIG 05-005 |
| 2. | 2446U236F1 | [1] | CLEANER ASSY, AIR SEE FIG 05-004 | CLEANER ASSY, AIR SEE FIG 05-004 |
| 3. | 2427R702 | [1] | MUFFLER | KOB |
| 4. | 2416P12003 | [2] | STAY | KOB |
| 5. | 2416N3190 | [1] | BRACKET | KOB |
| 6. | 2432Z162D5 | [2] | BAND | BAND |
| 7. | 2416P12137 | [1] | BRACKET | KOB |
| 8. | 2416P12138 | [1] | BRACKET | KOB |
| 9. | 2418T17962 | [2] | PLATE | KOB Superseded by part number: 2418T25775 |
| 10. | 2416Z498 | [4] | RUBBER SLEEVE | KOB |
| 11. | 2427T868 | [1] | RIGID TUBE | KOB |
| 12. | 2444R926 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R2457 |
| 13. | 2444R927 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R2458 |
| 14. | 2427T870 | [1] | EXHAUST SYSTEM PIPE | KOB |
| 15. | 2444R925 | [1] | FLEXIBLE HOSE | KOB |
| 16. | 2432T2369 | [1] | CLAMP | KOB |
| 17. | ZC15X06000 | [4] | CLIP | KOBCLIP |
| 18. | 2420T4454 | [2] | U-BOLT | KOB |
| 19. | ZS13C10025 | [6] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 20. | ZS13C18080 | [2] | SCREW | KOBM18x2.0x80mm |
| 21. | ZN13C18015 | [4] | NUT | KOBM18x2.5mm |
| 22. | ZN13C10008 | [5] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 23. | ZN13C08007 | [15] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 24. | ZW22X10000 | [33] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 25. | ZC15X10500 | [4] | CLIP | KOB |
| 26. | 2432R218 | [1] | CLAMP | KOB |
| 27. | 2414T2951 | [1] | COVER | KOB |
| 28. | 2414T2952 | [1] | COVER | COVER |
| 29. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 30. | ZN13C12010 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 31. | ZW22X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 32. | 2444Z1293D8 | [1] | LUBE NIPPLE | KOB1/4"PTx43mm Long Superseded by part number: R44T0022 |
| 33. | 2420Z795D3 | [1] | HOSE | KOB Superseded by part number: HX11Y07100DX |
| 34. | ZC15X01000 | [12] | CLIP | KOB |
| 37. | 2489R148 | [1] | SENDER UNIT | KOB |
| 38. | 2416P8513 | [1] | BRACKET | BRACKET |
| 39. | 2416T10844 | [1] | BRACKET | KOB |
| 40. | 2427U203P3 | [1] | RADIATOR SUB-TANK | |
| 40-2. | 2427U203S2 | [1] | HYD CONNECTOR | KOB |
| 40-3. | 2427U203S3 | [1] | LABEL | KOB |
| 40-4. | 2427U203S4 | [1] | TANK | KOB |
| 40-6. | 2427U203S6 | [1] | SWITCH | KOBRadiator Over Flow Level |
| 41. | 2420Z912D4 | [1] | HOSE | KOB |
| 42. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 43. | 2418Z560D1 | [1] | HOSE | KOB |
| 44. | ZS13C08030 | [6] | SCREW | KOBM08x1.25x30mm Superseded by part number: ZS18C08030 |
| 45. | ZW22X08000 | [7] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 46. | ZS13F10025 | [7] | SCREW | KOBCAPSCREW Superseded by part number: ZS18F10025 |
| 47. | ZN13F10008 | [1] | NUT | KOB Superseded by part number: ZN18F10008 |
| 48. | ZS13C16035 | [2] | SCREW | KOBM16x2.0x35mm |
| 49. | ZW22X16000 | [6] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 50. | ZS13C12025 | [2] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 51. | ZW13H12000 | [2] | WASHER | KOB |
| 52. | ZS13C18120 | [1] | CAPSCREW M18x2.0x120mm | CAPSCREW M18x2.0x120mm |
| 53. | 2420T4376D3 | [1] | SCREW | KOB |
| 55. | ZS13C10035 | [2] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 56. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 57. | 4018Z1D31 | [1] | FLEXIBLE HOSE | KOB |
| 58. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| 59. | ZS13C10020 | [16] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 61. | 4018Z1D10 | [1] | FLEXIBLE HOSE | KOB |
| 62. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 63. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 64. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 65. | 2416Z565D2 | [1] | INSULATOR | KOB |
| 66. | 2446U180 | [1] | SEPARATOR | KOB Superseded by part number: 2446U180F2 |
| 68. | 4018Z1D33 | [1] | FLEXIBLE HOSE | KOB |
| 69. | 2418N4581 | [1] | TUBE | TUBE |
| 71. | 2418T17674 | [1] | PLATE | |
| 72. | 4018Z1D30 | [1] | TUBE, VINYL | TUBE, VINYL |
| 73. | 2416Z573 | [2] | RUBBER SLEEVE | KOB |
| 74. | 2416Z574 | [2] | RUBBER SLEEVE | KOB |
| 75. | 2418T18173 | [4] | COLLAR CLAMP | KOB |
| 77. | ZC15X07000 | [1] | CLIP | KOB |
| 78. | 2420Z912D7 | [1] | FLEXIBLE HOSE | KOB |
| 79. | 2450R163F1 | [1] | INDICATOR | KOB Superseded by part number: LE11P01015F1 |
| 81. | ZC45X16011 | [1] | CLAMP | KOB Superseded by part number: ZC46X16011 |
| 82. | ZW16P06000 | [1] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 83. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 84. | ZS18C06016 | [1] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 85. | 2432R226D7 | [3] | CLIP Clamp, Double -- ID 16 x 66mm Long | CLIP Clamp, Double -- ID 16 x 66mm Long |
| 87. | 2444R942D3 | [1] | HOSE | KOB |
| 88. | 2479Z1435 | [1] | SENSOR | KOB Superseded by part number: VAMC845235 |
| 89. | 2444Z1600D3 | [1] | ELBOW UNION | KOBUnion Elbow Superseded by part number: 2444R620 |
| 90. | 2418P18416 | [1] | TUBE | TUBE |
| 91. | ZC15X08000 | [1] | CLIP | KOB |
| 99. | 24100N4106F3 | [1] | PUMP ASSY,CONNECT,SEE FIG 05-003 | |
| 100. | 2432R234 | [1] | CLAMP | KOB |
